Pro-Form 475 Audio Series User Manual page 12

14. Attach the ground wire on the Upright Wire (28)
to the indicated hole in the Base (48) with a
Silver Ground Screw (27).
Press the indicated grommet into the Right
Upright (36).
Slide the Right Base Leg Cover (94) onto the
Base (48) as shown. Attach the Right Base Leg
Cover with three 1/2" Screws (6). Be careful not
to pinch the Upright Wire (28). Do not over-
tighten the Screws.
15. Slide the Left Base Leg Cover (96) onto the Base
(48) as shown. Attach the Left Base Leg Cover
with three 1/2" Screws (6). Be careful not to
overtighten the Screws.
16. Tighten a 1/2" Screw (6) into each side of the
Base (48) and each Base Leg Cover (96, 94). Be
careful not to overtighten the Screws.
14
Grommet
28
Ground Wire
48
15
16
96
12
6
36
27
6
94
6
6
6
48
96
6
48
6
94
