Connecting a PremierWave Device—Network Method
Choose the desired connection method for your PremierWave, and then follow the instructions in
the corresponding section. You have three options for connecting to PremierWave:
1. Wired connection via Ethernet cable.
2. Wireless connection via Wireless router (Infrastructure)*
3. Wireless connection via Wireless card (Adhoc – factory default)*
Notes:
*Options listed above are only applicable to the PremierWave EN model.

Option 1: Wired connection via Ethernet

1. Connect the PC to the PremierWave Evaluation Board with a cross-over cable or a
hub/switch and two RJ45 cables. Make sure there is no router between the PC and the
Evaluation Board.
2. Select the appropriate power plug adaptor for your geographical location. Insert it into the slot
on the Universal Power Supply; then plug the power supply into an outlet.
3. Connect the output plug of the power supply to the PremierWave Evaluation Board.
4. Move the power switch on the Evaluation Board to ON. This is the last step in 'connection.'
The PremierWave is ready for configuration.
5. Continue with

Option 2: Wireless connection via Access Point or Wireless Router

(PremierWave EN model only)

1. Ensure the PC communicates with the access point (AP) or wireless router (WR) and that the
AP or WR is running correctly.
2. Ensure the PC is on the LAN (not the WAN) side of the AP or WR.
3. Make sure there is no other router between the PC and the AP or WR.
4. Change the AP or WR configuration as follows:
a. Set the Network name (SSID) to the Lantronix Initial Infra Network.
b. Disable all wireless security (no encryption, no/open authentication).
PremierWave® Evaluation Board Quick Start
Installing DeviceInstaller on page
Connecting a PremierWave Device—Network Method
9.
7
