- Page 1 SLICING MACHINE Start L 220 Start L 250 Installation and Operation Manual S/N: Rev.: 2.0...
- Page 3 22.3.2006 Rev. 2.0 Dear Customer, Congratulations on deciding to choose our appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied customer like thou- sands of customers we have around the world. Please read this manual carefully.
- Page 4 22.3.2006 Rev. 2.0...
-
Page 5: Table Of Contents
22.3.2006 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 1 2. Safety ......................2 2.1 Safe use of the appliance ....................2 3. - Page 6 22.3.2006 Rev.
-
Page 7: General
22.3.2006 Rev. 2.0 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Safety
22.3.2006 Rev. 2.0 Safety 2. Safety 2.1 Safe use of the appliance All operators involved in the present machine use, installation, maintenance and servic- ing, must read this manual carefully. An operator must take care of cutting and electric danger: the machine has a sharp blade driven by electric motor. -
Page 9: Functional Description
22.3.2006 Rev. 2.0 Functional description 3. Functional description 3.1 Application of the appliance The machine must be used for cutting eatable products with sizes which are in relation to cutting capacity and with a weight that does not endanger its balance. Frozen and overseasoned products are not provided for use in the machine. -
Page 10: Operation Instructions
22.3.2006 Rev. 2.0 Operation instructions 4. Operation instructions 4.1 Before using the appliance Before starting the machine, always check that safety devices work right and machine is clean. Before loading or unloading the product on the platform, check that regulator knob is in home position and that blade is at standstill. -
Page 11: After Use
22.3.2006 Rev. 2.0 Operation instructions Machine Parts Platform Food pusher Slice thickness control knob ON/Off switch Grindstone Locking screw for the sharpener Blade Burr remover (for the sharpener) Push knob for the sharpener Blade covering Mounting screw for the sled Knob for the sharpener 4.3 After use 4.3.1 Cleaning... -
Page 12: Sharpening
22.3.2006 Rev. 2.0 Operation instructions 4.3.3 Sharpening Carry on with blade sharpening after checking that machine is switched off. It is necessary that blade is cleaned and grease is very well removed. Make sure that the machine is switched off. Loosen the knob (K) and lift the sharpening device upwards, turn it 180 degrees clockwise and lock to place by tightening the knob. -
Page 13: Installation
22.3.2006 Rev. 2.0 Installation 5. Installation 5.1 Unpacking the appliance At machine receipt check that packing is complete. All packing components are classified as solid urban waste; do not dispose of them in the environment. Take the machine out of the packaging by seizing it by its base; machine weight is spec- ified in the chapter “Technical Specifications”... - Page 14 22.3.2006 Rev. 2.0 Installation...
-
Page 15: Technical Specifications
22.3.2006 Rev. 2.0 Technical specifications 7. Technical specifications Wiring diagram Installation drawing... - Page 16 Wiring diagram...
- Page 17 Installation drawing...
- Page 18 22.3.2006 Rev. 2.0 Technical specifications Item Specification Blade diameter 220 mm, 250 mm Slice thikness 15 mm Cut capacity 190x130 mm, 200x160 mm Power 0,10 kW, 0,14 kW Weight, net 13 kg, 16 kg 220=Start L 220, 250=Start L 250...
