BRATT PAN
FUTURA PE
FUTURA PES
FUTURA PED
TYPE: 60, 85, 110
Accessories
HEIGHT ADJUSTMENT
Installation and Operation Manual
S/N: 095441/01
Valid from: 13.10.2009
Rev.: 3.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the pes 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Metos pes 60

  • Page 1 BRATT PAN FUTURA PE FUTURA PES FUTURA PED TYPE: 60, 85, 110 Accessories HEIGHT ADJUSTMENT Installation and Operation Manual S/N: 095441/01 Valid from: 13.10.2009 Rev.: 3.6...
  • Page 3: Table Of Contents

    26.10.2009 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 1 2. Safety ......................2 2.1 Safe use of the appliance ....................2 2.2 Safety instructions in case of malfunction ..............
  • Page 4 26.10.2009 Rev. 8. Technical specifications ................29...
  • Page 5: General

    26.10.2009 Rev. 3.6 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations.
  • Page 6: Safety

    26.10.2009 Rev. 3.6 Safety 2. Safety 2.1 Safe use of the appliance Because the bratt pan is a heated appliance that has hot surfaces during normal use, the following warnings and instructions must be followed to avoid burns. • During long-time operation even the sides of the frying surfaces, the pouring lip and the lid get hot.
  • Page 7: Functional Description

    26.10.2009 Rev. 3.6 Functional description 3. Functional description 3.1 Intended use of the appliance The Futura PE bratt pan is intended for heating and frying of food. 3.1.1 Use for other purposes Use of the appliance for other purposes than stated above is prohibited. The manufacturer of the appliance takes no responsibility for situations that may occur if warnings and instructions in this manual are neglected.
  • Page 8: Operation Instructions

    26.10.2009 Rev. 3.6 Operation instructions 4. Operation instructions 4.1 Before use 4.1.1 Preparing the use The frying surface of the bratt pan is protected with a thin layer of grease during storage and transportation. Before first-time use the grease must be removed by using hot water and detergent.
  • Page 9: Setting Of The Frying Temperature

    26.10.2009 Rev. 3.6 Operation instructions Tilting Return The pan is switched on by pressing the ON/OFF button, whereafter • the heating-up starts • the green pilot light goes on • the temperature displays show the preset temperature of 180°C (only one display in model PE 60).
  • Page 10: Frying Temperature

    26.10.2009 Rev. 3.6 Operation instructions • The heating-up of the other zone can be switched off by setting the temperature to 0°C. The preset frying temperature 180°C remains in memory and is activated for use by switching off the pan with the ON/OFF button and then turning it on again. During long-time use, heat is transferred from one zone to the other.
  • Page 11: Adjusting The Working Height

    26.10.2009 Rev. 3.6 Operation instructions 4.2.5 Adjusting the working height Before adjusting the working height of the bratt pan, check that nothing is in the move- ment area or leaning against the moving part of the bratt pan. Adjustment of the working height is possible in bratt pan models with letter H included in the model marking.
  • Page 12: Service

    26.10.2009 Rev. 3.6 Operation instructions The frying surface of the pan is rinsed with hot water, dried by heating up and greased with salt-free grease. All other surfaces are rinsed and wiped dry. Water usage on the control panel and the electric box must be avoided. Use of a water hose or pressure cleaning jet is strictly forbidden.
  • Page 13: Installation

    26.10.2009 Rev. 3.6 Installation 5. Installation 5.1 Transporting and unpacking the bratt pan The best way to move the bratt pan is to keep it in its own package as long as possible while it also protects the pan from outer damage. If it is necessary to unpack the pan, pos- sible lifting must thereafter be done from the bottom frame of the base by using suitable spacers of wood.
  • Page 14: Test-Run

    26.10.2009 Rev. 3.6 Installation 5.4 Test-run Besides the live electrical parts also look out for possible moving mechanisms in the low- er part of the appliance, if there is a need for testing the appliance during installation while the guards or cover plates are detached. Make sure that the protective grease has been removed from the frying surface before tak- ing the pan into use.
  • Page 15: Troubleshooting

    26.10.2009 Rev. 3.6 Troubleshooting 6. Troubleshooting If the appliance does not function, check the following: • Has the appliance been used according to the instructions? • Are all possibly removable parts refitted? • Are the mains switch on the appliance or nearby - often on the wall - in the ON position? If even this does not help, figure out in advance how to briefly describe the break-down and contact an authorized service person.
  • Page 16 26.10.2009 Rev. 3.6 Troubleshooting...
  • Page 17 26.10.2009 Rev. 3.6 Technical specifications 8. Technical specifications Heating control, circuit board connections Heating control Heating control, circuit board connections Wiring diagram T00558B4 Wiring diagram T00185A3 Wiring diagram T00184C3 Wiring diagram T00942C3 Main and control circuit 82947N83 Heating element connection 81591-83 Installation drawing 80800-63C...
  • Page 18 Heating control, circuit board connections [PE; 60]...
  • Page 19 1. Lämmityselementit 5. Säätökortti, vasen (1) Värme-element Styrkort, vänster Heating elements Regulation card 2. Lämmityselementtien kaapelit 6. Säätökortti, oikea (2) Värme-elementens kablar Styrkort, höger Cables to heating elements Regulation card, right 3. Termolangat (tuntoelin) 7. Vasemman vyöhykkeen ohjaus (1) Termoelement (givare) Vänstra zonens styrning Thermocouple (sensor) Left zone control...
  • Page 20 Heating control, circuit board connections [PE; 85, 110]...
  • Page 21 Wiring diagram T00558B4 [PE 60]...
  • Page 22 Wiring diagram T00185A3 [PE 60]...
  • Page 23 Wiring diagram T00184C3 [PE 85, 110]...
  • Page 24 Wiring diagram T00942 C3...
  • Page 25 Main and control circuit 82947N83 [PE; 85, 110]...
  • Page 26 Heating element connection 81591-83 [PM, PE]...
  • Page 27 Installation drawing 80800-63C [PE]...
  • Page 28 26.10.2009 Rev. 3.6 Technical specifications Item Model Type Voltage Specification Dimensions WxDxH PM,PE 600x8000x940 mm Dimensions WxDxH PM,PE 850x800x940 mm Dimensions WxDxH PM,PE 1100x800x940 mm Package dimensioner WxDxH PM,PE 720x900x1200 mm Package dimensioner WxDxH PM,PE 980x900x1200 mm Package dimensioner WxDxH PM,PE 1220x900x1200 mm Frying zones...
