Important
Keep the Pen Tray
mounting brackets
stationary as you
remove the screws.
Warning
Do not force the Board
to fit an uneven wall
surface. This may
cause the SMART
Board to warp or bend,
causing it to
malfunction and
produce a constant
contact (see glossary).
14
1. Disconnect the mini RJ11 connector end of the MOD4 cable from
the rectangular socket labeled "BOARD" on the right side of the
Pen Tray.
2. Detach the Pen Tray by removing the screws that fasten the Pen
Tray to the Pen Tray mounting brackets at the bottom of the Pen
Tray.
The Pen Tray brackets will remain attached to the whiteboard.
3. Use a pencil to mark the position of the two holes in the Pen Tray
brackets that will secure the Pen Tray to the wall.
4. Rotate both Pen Tray brackets out of the way of the pencil marks
just made on the wall.
5. Insert a drywall anchor at each pencil mark, tightening until snug
in the wall.
6. If the wall is uneven, "shim" the wall by inserting a thin slip or
wedge of wood between the wall and the Pen Tray mounting
brackets to create an even surface for fastening the bottom of
the whiteboard.
7. Rotate the Pen Tray brackets back in place over the drywall
anchors. Then use the two Robertson pan-head screws to fasten
the Pen Tray mounting brackets to the drywall anchors. Tighten
to hold the whiteboard in place.
8. Reattach the Pen Tray to the Pen Tray brackets with the four
screws you removed in Step 2.
9. Reconnect the MOD4 cable to the Pen Tray by reinserting the
mini RJ11 connector into the rectangular socket on the right side
of the Pen Tray labeled "BOARD".
Connecting the Pen Tray to the Computer
and Power Source
You will now connect the Pen Tray to the computer and the power source
to enable all parts of the SMART Board to communicate with each other.
