Warning
Avoid resting the
bottom of the
whiteboard against
the floor as the Pen
Tray could sustain
damage from its
weight.
12

Mounting the SMART Board

Two people are required to complete this procedure, one person standing
at either side of the whiteboard. The weight of the whiteboard should be
supported at the bottom corners and balanced at the top as it is lifted up,
so that the bracket on the back of the whiteboard meets the open slot of
the wall bracket.
"Step 2: Secure the Pen Tray to the wall" only needs to be performed if
the whiteboard does not remain rigid and stationary when pressed along
its bottom edge.
Step 1: Mount the whiteboard on the wall
1. Lift the whiteboard from its side-resting position to the top of the
open end of the wall bracket, making sure its weight is fully
supported at the bottom corners.
2. Lower the whiteboard onto the wall bracket, sliding the bracket
on the back of the whiteboard down into the open slot of the wall
bracket.
3. Ensure the whiteboard is securely fixed on the wall bracket by
holding it firmly at both sides, and then attempting to pull it away
from the wall. If the whiteboard pulls away from the bracket, it is
only partially engaged. Lift the whiteboard up and slide it into the
wall bracket again.
Step 2: Secure the Pen Tray to the wall
Press the whiteboard along its bottom edge. If the whiteboard
remains stationary, skip this procedure. If the whiteboard shifts, you
should attach the Pen Tray directly to the wall to entirely eliminate any
whiteboard movement.
To accomplish this, disconnect the MOD4 cable from the Pen Tray,
remove the Pen Tray from its brackets, secure the brackets to the wall,
and then reattach the Pen Tray to its brackets.
SMART Board Installation Guide
