Part Numbers - GE Security DVMRe Matrix User Manual

Video
Video Signal Input
Video Signal Output
Input Termination
Display Memory
Resolution
Gray Scale
Colors
Compression Standard
Audio
Audio Input
Audio Output
Alarms
Inputs
Relay Configuration
Record Priority
Alarm Status Indicators
Motion Detection
Zones Per Camera
Sensitivity Settings
Gray Levels Per Zone
Motion Detection Status
Output

Part Numbers

Remote Keyboard
Rack Mount Kit
Replacement Manual
0150-0242D
0.5 to 2.0 Volts peak-to-peak with Automatic Gain Control.
1 Volt peak-to-peak into 75-Ohm.
75-Ohm (Auto Terminating)
4 Megabytes
Horizontal: 720 Pixels. Vertical: 484 Lines (576 for PAL).
256 levels
Y:U:V 4:2:2, 16.8 Million Colors
Wavelets
RCA jack, 315mV, 40k Ohms. Unbalanced.
RCA jack, 315mV, 600 Ohms. Unbalanced.
1 per camera.
User programmable as Normally Open or Normally Closed.
Interleaved, Exclusive, or No Change.
Relay Outputs, On-screen Indicators. Status Retrievable via RS232
port.
256: 16 x 16 grid.
10 levels
256 levels
Relay Outputs, Link to Alarms, Link to Events, On-screen Indicators.
Status retrievable via RS232 port.
CBR-KB3, CBR-KB3/J, KTD405. Includes motorized pan, tilt, and zoom
controls.
CBR-RK6. 1U Height. Part Number: 0110-R601
0150-0242
87 GE Security DVMRe Matrix
