Selecting a Camera Full-Screen on Monitors A through E
While the monitor's LED is on, press a camera number button.
Starting Sequencing on Monitors A through E
While the monitor's LED is on, press the sequence button.
Canceling Sequencing on Monitors A through E
To select a fixed display on Monitors A through E:
While the monitor's LED is on, press either the sequence key or a
camera number key.

2.7 Active Cameos

A cameo is defined as any cell within a multiscreen display. Active Cameo mode allows the user to
access and edit each cameo individually.
Entering Active Cameo Mode
While viewing a multiscreen, enter Active Cameo mode by pressing the Enter
button. Active Cameo mode is indicated on-screen by flashing the number
and titles of the active cameo and the LED above the Enter button is lit. By
default, the top left cameo is activated.
Selecting Cameos
Select a cameo using the Jog/Shuttle to navigate the multiscreen. Rotating
the Jog selects the next screen up or down a row. Rotating the shuttle
selects the next screen in numerical order. The active cameo will always be
indicated by the flashing camera number and titles.
Selecting Cameras
Display any camera in the active cameo by pressing the Number button of
the desired camera. Once a camera has been selected, the active cameo
advances to the next cameo on the right.
The camera selection only changes the multiscreen currently being displayed. Each multiscreen must
be configured separately. Changes to the multiscreen display are saved in non-volatile memory, and
will be retained even if power is removed from the unit.
0150-0242D 22
1
Camera Number Button
Sequence Button
Sequence Button
Enter Button
Jog/Shuttle
1
Number Button
