2. Product Specifications
For all the following specifications, values are defined at ambient temperature and nominal supply voltage unless
otherwise stated.
2.1. System Environmental Specifications
Temperature
Humidity
Acoustic Noise
Vibration
Shock
Altitude
(relative to sea level)
2.2. System Power Requirements
(Maximum Average Value)
See Notes.
NOTES: All values quoted are typical at ambient temperature and nominal supply voltage unless otherwise stated.
Sleep mode currently is specified under the condition that all card inputs are static CMOS levels and in a
"Not Busy" operating state.
The currents specified show the bounds of programmability of the product.
®
CompactFlash
Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION
Table 2-1. Environmental Specifications
Non-Operating:
Non-Operating:
Non-Operating:
Non-Operating:
Non-Operating:
Table 2-2. Power Requirements
DC Input Voltage (VCC)
100 mV max. ripple (p-p)
Sleep:
Reading:
Writing:
Read/Write Peak:
Operating:
0° C to 60° C
-25° C to 85° C
Operating:
8% to 95%, non-condensing
8% to 95%, non-condensing
0 dB
Operating:
15 G peak to peak maximum
15 G peak to peak max
Operating:
2,000 G maximum
2,000 G maximum
Operating:
80,000 feet maximum
80,000 feet maximum
3.3V ±5%
200 µ A
21 mA
21 mA
100 mA
5V ± 10%
500 µ A
34 mA
34 mA
100 mA
2-1
