2.0 Product Specifications

For all the following specifications, values are
defined at ambient temperature and nominal
supply voltage unless otherwise stated.
2.1 System Environmental
Specifications
Temperature
Humidity
Acoustic Noise:
Vibration
Shock
2.2

System Power Requirements

DC Input Voltage (VCC)
100 mV max. ripple (p-p)
+5 V Currents
(maximum Average value)
See Notes 1 to 3.
Note 1. All values quoted are typical at ambient temperature and nominal supply voltage unless otherwise stated.
Note 2. Sleep mode currently is specified under the condition that all card inputs are statis CMOS levels and in a
"Not Busy" operating state.
Note 3. The currents specified show the bounds of programmability of the product.
SanDisk CompactFlash Memory Card Product Manual © 1998 SANDISK CORPORATION
CompactFlash Memory Card Product Manual
Operating: 0° C to 60° C
Non-Operating: -25° C to 85° C
Operating: 8% to 95%, non-condensing
Non-Operating: 8% to 95%, non-condensing
0 dB
Operating: 15 G peak to peak max.
Non-Operating: 15 G peak to peak max.
Operating: 2,000 G max.
Non-Operating: 2,000 G max.
(Standard Version)
3.3V ±5%
Sleep: 200 µA
(Slow - Fast)
Reading: 32 mA - 45 mA
Writing: 32 mA - 60 mA
Read/Write Peak 150 mA/50µs
Standard SDCFB-XX
Product
SDCFB-XX
5V ± 10%
500 µA
(Slow - Fast)
46 mA - 75 mA
46 mA - 90 mA
150 mA/50µs
Industrial SDCFBI-XX
Product
-40° C to 85° C
-50° C to 100° C
8% to 95%, non-condensing
8% to 95%, non-condensing
0 dB
15 G peak to peak max.
15 G peak to peak max.
2,000 G max.
2,000 G max.
SDCFBI-XX
(Industrial Version)
3.3V ±5% 5V ±5%
200 µA 500 µA
(Slow - Fast) (Slow - Fast)
32 mA - 45 mA 46 mA - 75 mA
32 mA - 60 mA 46 mA - 90 mA
150 mA/50µs 150 mA/50µs
