Pro-Form 420 Ce Elliptical Manual page 12

12. Identify the Right Rear and Front Leg Covers
(29, 30).
Attach the Right Rear Leg Cover (29) to the
Right Upper Body Leg (6) with three M4 x 16mm
Screws (93).
Attach the Right Front Leg Cover (30) around
the Right Upper Body Leg (6) by pressing the
tabs on the Right Front Leg Cover into the Right
Rear Leg Cover (29).
Attach the Left Rear and Front Leg Covers
(31, 32) in the same way.
See step 3. Tighten the four M8 x 16mm
Screws (102).
Then, slide the Top Cover (23) downward and
press it over the Frame (1).
13. Plug the Power Adapter (79) into the receptacle
at the back of the elliptical.
Note: To plug the Power Adapter (79) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 13.
14. Make sure that all parts of the elliptical are properly tightened. Note: Extra parts may be included. To
protect the floor or carpet from damage, place a mat under the elliptical.
12
32
31
29
23
1
13
79
12
30
6
93
