3.16 TI50 Thruster Interface

Dimensions: ............................................................................................... See Figure 3-13
Weight: ....................................................................................................... 0,8 kg (1.8 lbs)
Material:...................................................................................... Epoxy coated aluminium
Environmental Protection: .......................................................................................... IP44
Supply and interface: ........................................................................RobNet, 2 connectors
Cable inlets: .......................................................Rubber glands for cable diam. 10-14 mm
Mounting: ................................................................................................. Bulkhead mount
Compass safe distance: ................................................................................. 0.2 m (0.7 ft)
Temperature range:
Operation: .................................................................... –25 to +55°C (–13 to +130°F)
Storage:........................................................................ –30 to +80°C (–22 to +176°F)
Thruster drive interface:
Danfoss PVEM:................... Nominal U
Analog control, internal supply: ...Control range±10V, max. 5 mA, galvanic isolated
Analog control, external supply: ............... U
ON/Off valve:...............................Port/stbd on/off, open collector, galvanic isolated,
Thruster enable output: ................... Open collector, external or internal +, max 500 mA.

3.17 AD50 Analog Drive

Dimensions: ............................................................................................... See Figure 3-13
Weight: ....................................................................................................... 0,8 kg (1.8 lbs)
Material:...................................................................................... Epoxy coated aluminium
Environmental Protection: .......................................................................................... IP44
Supply and interface: ........................................................................RobNet, 2 connectors
Cable inlets: .......................................................Rubber glands for cable diam. 10-14 mm
Mounting: ................................................................................................. Bulkhead mount
Compass safe distance: ................................................................................. 0.2 m (0.7 ft)
Temperature range:
Operation: .................................................................... –25 to +55°C (–13 to +130°F)
Storage:........................................................................ –30 to +80°C (–22 to +176°F)
20221032B
DC
valve saturated for<0.25*U
The internal +12V output is limited to 100mA
and may be used for an external relay operated by Hi/Lo output
to switch thruster control signal between autopilot
Technical Specifications
=12/24V, I=0.25/0.5mA, neutral 0.5*Un,
control range 0.25*U
12-24VDC, control range 0- U
DC
external common plus or minus, 3A max.
and external manual control.
to 0.75*U
DC DC
or >0.75*U
DC DC
or
DC
±U /2, max. 5 mA
DC
