Simrad AP50 Instruction Manual page 132

Simrad AP50 Autopilot
Set-up item
(abbrev. name)
GYRO2
THD1
THD2
MAGN1
CD100A + CDI35
CD100A
MAGN2
CD100A + CDI35
CD100A
130
Equipment
connected (use one available from list)
(name)
Not connected
Connection to RobNet
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
GI51/CI300X, Gyro terminal
GI51/CI300X, Gyro terminal
GI51/CI300X, Gyro terminal
GI51/CI300X, Gyro terminal
Not connected
Connection to RobNet
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
Not connected
Connection to RobNet
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
Not connected
Junction unit: HS+, HS–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
CI300X Magnetic Compass terminal
Not connected
Junction unit: HS+, HS–
J50, Power PCB NMEA I/P RX2+,RX2–
NI300X, NMEA port #1
NI300X, NMEA port #2
NI300X, NMEA port #3
NI300X, NMEA port #4
CI300X Magnetic Compass terminal
Connected to terminal Assign hardware
port to set-up item
(* = default setting)
– – – – *
ROBNET **
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
GI-sync
GI-step
GI-0183
GI-prop
– – – – *
ROBNET **
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
– – – – *
ROBNET**
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
– – – – *
J50-HS
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
CI300X
– – – – *
J50-HS
J50-2
NI300-1
NI300-2
NI300-3
NI300-4
CI300X
20221032B
