1.3 System Components

20221032B
At the end of this manual, you will find an index and a glossary,
which will help you when studying the manual.
Other documentation provided with your system includes a
warranty card.
The Warranty Card must be completed by the authorized dealer
that performed the installation and mailed-in to activate the
warranty.
A basic AP50 system may consist of the following units (refer to
Figure 1-1):
• AP50 Control Unit with accessories
• Heading Sensor
• Rudder Feedback Unit with transmission link
• Junction Unit
• Drive Unit
The basic system can be expanded with remote control unit,
hand held remote and steering lever.
Figure 1-1 AP50 Basic system
