Processor

The SCB2 accommodates one or two Intel Pentium III processors with 512k cache in the FC-PGA2
package. This processor uses the .13 micron technology and offers advanced performance. The
processor external interface operates at a maximum of 133 MHz. For a complete list of supported
processors see:
http://support.intel.com/support/motherboards/server/scb2

Memory

The system board contains six 168-pin DIMM slots each supporting 72-bit ECC (64-bit main
memory plus ECC) registered SDRAM DIMMs (PC-133 compatible). Memory is two-way
interleaved and partitioned in three banks. You may install a minimum of 128 MB (64MB x 2) and
as much as 6 GB.
The controller automatically detects, sizes, and initializes the memory array, depending on the type,
size, and speed of the installed DIMMs, and reports memory size and allocation to the server via
configuration registers.
NOTE
Use DIMMs that have been tested for compatibility with the server board.
Contact your sales representative or dealer for a current list of approved
memory modules. Check the Intel Customer Support website for the latest
tested memory list:
http://support.intel.com/support/motherboards/server/scb2

PCI Riser Slots

The server board has two PCI riser slots, each capable of supporting 64-bit/66-MHz PCI riser cards.
PCI features:
Bus speed up to 66 MHz
32 bit memory addressing
5 V/3.3 V signaling environment
Burst transfers of up to 512 Mbps
8, 16, 32, or 64-bit data transfers
Plug and Play ready
Parity enabled
