Intel
Server Board S5520HC,
®
Intel
Server Board S5500HCV,
®
Intel
Workstation Board S5520SC,
®
Intel
Server Chassis SC5600,
®
Intel
Server Chassis SC5650
Spares Parts List & Configuration Guide
A reference guide to assist customers in ordering the necessary components to configure the
®
Intel
Server Board S5520HC, Intel
S5520SC with appropriate Intel chassis.
®
Server Board S5500HCV, and Intel
®
Workstation Board
Rev 1.01
Feb, 2009
~ Subject to Change ~
I
Advertisement
Table of Contents
Related Manuals for Intel S5500HCV
Summary of Contents for Intel S5500HCV
- Page 1 A reference guide to assist customers in ordering the necessary components to configure the ® Intel Server Board S5520HC, Intel S5520SC with appropriate Intel chassis. ® Server Board S5500HCV, and Intel ® Workstation Board Rev 1.01 Feb, 2009 ~ Subject to Change ~...
- Page 2 Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.
-
Page 3: Table Of Contents
System Management Software – (Upgrade SKUs)... 21 ® Intel System Management Software – Upgrade Order Codes: ... 22 ® Production Intel Xeon Processor 5500 Series ... 23 Production Intel Thermal Solution STS100 Series ... 24 Heat Sink Configuration Guide ... 24... -
Page 4: Production Configuration
The Intel Server Chassis SC5600LX is designed to work with Intel 95W maximum power using special FXXRGTHSINK tower heat sink accessory. The production Intel Server Chassis SC5600BRP KDK is compatible with the Intel and S5500HCV. it includes: • Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support redundancy 750W high efficiency PFC module included) •... - Page 5 The Intel Server Chassis SC5600BRP is designed to work with Intel 95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink. The production Intel Server Chassis SC5600 Base KDK is compatible with Intel S5500HCV, and Intel® Workstation Board S5520SC. It includes: •...
- Page 6 AXX4DRV3GEXP: Expander-based 4-drive bay that supports SAS/SATA drives. Requires two free – SAS ports from the SAS module or SAS RAID card. Only supported in Intel SC5600BRP,and SC5600LX. AXX6DRV3GR: 6-drive bay that supports SAS/SATA drives. Requires six free SAS or SATA ports.
- Page 7 APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis family. This kit should be used with AXX6DRV3GEXP.
-
Page 8: Production Board Skus
901634 00735858207539 Bulk pack of the Intel Description ® Server Board S5520HC. (Includes I/O shield, ® Server Board S5520HC ® Server Board S5500HCV. (Includes I/O shield, ® Server Board S5500HCV ® Workstation Board S5520SC. (Includes I/O ® Workstation Board S5520SC. -
Page 9: Production Chassis
PSU, 3 fixed chassis fans with ducting, 1 PSU fan. Supports up to 6 tool-free cabled drives, upgradeable to 6 hot-swap drives (SAS or SATA). Supports Intel Board S5520HC, S5500HCV and Intel S5520SC. Supports up to 95W processor. No power cord or heat sinks included. - Page 10 10 fixed, cabled drives or 10 (6+4 configuration) hot-swap SAS or SATA drives. Supports Intel® Server Board S5520HC, S5500HCV. Supports up to 95W processor. No power cord or heat sinks included. Special tower heat sink FXXRGTHSINK can be purchased as an accessory.
-
Page 11: Production Spares And Accessories
4-drive hot-swap expander, SATA/SAS backplane assembly 877236 00735858180290 cage kit for Intel Server Chassis SC5650 family. Requires 2 SAS ports from SAS personality module or RAID card and is compatible with SAS or SATA 3.5” hard drives. Includes: Backplane board, 4 drive carriers, 2 data cables, 4-drive bay, IPMB cable, common installation guide, SATA/SAS configuration label. - Page 12 4-drive hot-swap non-expanded, SATA/SAS backplane assembly 00735858207645 cage kit for Intel Server Chassis SC5600 family. Requires 4 SAS ports from RAID card for SAS (or SATA) 3.5” hard drive support or 4 SATA ports from baseboard or RAID card for SATA 3.5”...
- Page 13 Redundant 600W PSU for Intel Server Chassis SC5650BRP to enable full, hot-swap power redundancy or use as spare 00735858164702 Cabled 4 drive tool-less drive bay assembly for Intel Server Chassis SC5600. Includes hardware to mount 4 additional non- hot swap drives (for total of up to 10).
- Page 14 Server Chassis SC5600BRP and LX Redundant Power Supply Power Distribution Board 00735858207706 Spare fixed 4-wire fan kit for Intel and SC5600BRP. Includes 1 front Fan (120mm), 1 rear chassis fan (120mm, blue header), and 1 front PCI zone fan (92mm).
- Page 15 00735858155212 for DSD and one for DCD (modem). The kit also includes one serial ribbon cable for cabling 2nd serial port from the baseboard. Note: Not use the serial ribbon cable with the Intel Server Chassis SC5600/SC5650 00735858206389 Spare board for AXX4DRV3GR (4 drive backplane without an expander).
- Page 16 3.5” HDD (cabled) or a 3.5” USB floppy in a standard 5.25” drive bay. Remove the bracket bezel for 3.5” HDD installation. 00735858164610 DLT Accessory Kit for Intel and right rails (10 Pack) Permits mounting a full height 5.25” peripheral (e.g. DLT tape drive) in two half height bays. ®...
- Page 17 Holder with screws; 4 Hot Swap Fan Wires , 1 Bezel Intrusion Switch, 2 sets / 4 pcs 5.25” tool-less bay rails, 2 sets / 4 pieces of fixed hard drive bay rails, 4 chassis feet, 1 Air Duct for Intel Server SC5600BASE/BRP, 1 Air Duct for Intel Server Chassis...
-
Page 18: Production Raid Accessories (Not Including Bbu)
SC5650DP/WS MM # ® 900946 00735858206372 Intel port pass through SAS, entry-level RAID 0/1/1E, and optional host RAID 5.: Includes 1 AXX4SASMOD module card; 3 snap standoffs, 4 SAS/SATA cables, Configuration Label and Quick Installation Guide ®... -
Page 19: Production Raid Controller
892598 SRCSATAWB 892456 SRCSASLS4I 896952 ® 00735858201339 Intel RAID Controller SRCSAS16PHI - PCIe x8, 16P SAS RAID Controller, 256MB 667MHz memory embedded. ® 00735858196444 Intel RAID Controller SRCSASJV - PCIe x8, 8P SAS RAID Controller with Mux (ports can be configured as internal or external), ships with 512MB DIMM, supports up to 1GB ECC 7667MHz DDR2 mini-DIMM. - Page 20 MOQ = Minimum Order Quantity. MM # ® 00735858201360 896960 Intel RAID Controller SASMF8I - PCIe x4, 8P SAS Controller with Intel Embedded Server RAID technology, Low Profile, half length form factor. ® 00735858205115 Intel RAID Controller SASUC8I - PCIe x8, 8P SAS 900176 Controller with entry-level HW RAID 0/1/1E/10E, low profile, half-length MD2 compliant form factor.
-
Page 21: Intel ® System Management Software - (Upgrade Skus)
System Management Software – (Upgrade SKUs) ® The following Intel® System Management Software Upgrade SKUs are offered. Each SKU includes a Certificate of Authenticity (COA) that contains a product key for user to enter to upgrade: Upgrades available to Microsoft* System Center Essentials 2007 •... -
Page 22: Intel ® System Management Software - Upgrade Order Codes
SMS2CAL20C 7 35858 19674 1 Description 893177 Upgrade from Single Server Edition to Small Network Edition Not included: Software CDs are not included with upgrade. User must already have a valid copy of Microsoft* System Center Essentials 2007 to upgrade. -
Page 23: Production Intel ® Xeon Processor 5500 Series
Production Intel Xeon Processor 5500 Series ® Boxed Boxed Product Product Processor Name Code ® ® Intel Xeon Processor W5580 BX80602W5580 901024 ® ® Intel Xeon Processor X5570 BX80602X5570 901025 ® ® Intel Xeon Processor X5560 BX80602X5560 901026 ® ®... -
Page 24: Production Intel Thermal Solution Sts100 Series
Production Intel Thermal Solution STS100 Series Product name Description Recommended usage ® Intel Thermal Passive/Active With fan installed: Solution Combination Heat - Pedestal chassis that provide STS100C Sink with adequate ventilation and correct Removable Fan temperature air to heat sink...
