Onboard Devices Configuration

Onboard Device Configuration
High Definition Audio
Front Panel Type
PCIE GigaBit LAN 1
PCIE GigaBit LAN 2
LAN Boot ROM
VIA Firewire 1394
Marvell IDE/eSATA
IDE/eSATA Boot ROM
Speeding HDD Control
Speeding HDD Mode Update
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
High Definition Audio [Enabled]
Allows you to enable or disable the High Definition Audio. The following item
appears only when you enable this item.
Configuration options: [Enabled] [Disabled]
Front Panel Support Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy
AC'97 or high-definition audio depending on the audio standard that the front
panel audio module supports. Configuration options: [AC97] [HD Audio]
PCIE GigaBit LAN 1/2 [Enabled]
Configuration options: [Enabled] [Disabled]
LAN Boot ROM [Disabled]
Configuration options: [Disabled] [Enabled]
VIA Firewire1394 [Enabled]
Configuration options: [Enabled] [Disabled]
Marvell IDE/eSATA [Legacy Mode]
Allows you to enable or disable the onboard Marvell IDE/eSATA controller.
Configuration options: [Enabled] [Disabled]
IDE/eSATA Boot ROM [Enabled]
This item appears only when you enable the previous item.
Configuration options: [Disabled] [Enabled]
Speeding HDD Control [Auto]
Allows you to enable or disable the SPEEDING HDD1 and SPEEDING HDD2
ports. Configuration options: [Auto] [Enabled] [Disabled]
ASUS Maximus II Formula
BIOS SETUP UTILITY
Advanced
[Enabled]
[HD Audio]
[Enabled]
[Enabled]
[Disabled]
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Current Setting]
Enable or Disable
High Definition Audio
Controller
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
