Asus MAXIMUSII/FORMULA - Maximus II Formula Motherboard User Manual page 160

6. Use the up/down arrow key to select the stripe size for the RAID 0 array, and
then press <Enter>. The available stripe size values range from 4 KB to 128
KB. The default stripe size is 128 KB.
We recommend a lower stripe size for server systems, and a higher stripe size
for multimedia computer systems used mainly for audio and video editing.
7. Enter the RAID volume capacity that you want and press <Enter>. The default
value indicates the maximum capacity allowed.
8. Press <Enter> when the Create Volume item is highlighted. The following
warning message appears.
9. Press <Y> to create the RAID volume and return to the main menu, or <N> to
go back to the Create Volume menu.
4-44
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
Chapter 4: Software support
