3.1.2

ASUS EZ Flash 2 utility

The ASUS EZ Flash 2 feature allows you to update the BIOS without having to go
through the long process of booting from a floppy disk and using a DOS-based
utility. The EZ Flash 2 utility is built-in the BIOS chip so it is accessible by pressing
<Alt> + <F2> during the Power-On Self Tests (POST).
To update the BIOS using EZ Flash 2
1. Visit the ASUS website (www.asus.com) to download the latest BIOS file for
the motherboard.
2. Save the BIOS file to a floppy disk or a USB flash disk, then restart the
system.
3. You can launch the EZ Flash 2 by two methods.
(1) Insert the floppy disk / USB flash disk that contains the BIOS file to the
floppy disk drive or the USB port.
Press <Alt> + <F2> during POST to display the following.
FLASH TYPE:
PATH: A:\
(2) Enter BIOS setup program. Go to the Tools menu to select EZ Flash2
and press <Enter> to enable it.
You can switch between drives by pressing <Tab> before the correct file
is found. Then press <Enter>.
4. When the correct BIOS file is found, EZ Flash 2 performs the BIOS update
process and automatically reboots the system when done.
•
•
3-4
ASUSTek EZ Flash 2 BIOS ROM Utility V3.25
WINBOND W25P/X16
Current ROM
BOARD: Maximus-II Formula
VER: 0114
DATE: 05/09/2008
A:
Note
[Enter] Select or Load
[Up/Down/Home/End] Move
This function can support devices such as a USB flash disk or a floppy disk
with FAT 32/16 format and single partition only.
DO NOT shut down or reset the system while updating the BIOS to prevent
system boot failure!
Update ROM
BOARD: Unknown
VER: Unknown
DATE: Unknown
[Tab] Switch [V] Drive Info
[B] Backup [Esc] Exit
Chapter 3: BIOS setup
