OPT FAN1/2/3 overheat protection [90ºC]
Allows you to set the temperature over which the system automatically shuts
down when any of the thermal sensor cables connected to the motherboard
detects device overheat to protect the device from damage.
Configuration options: [Disabled] [70ºC] [80ºC] [90ºC]
Fan Speed Monitor
CPU Fan, Chassis Fan1/2/3, POWER Fan, OPT Fan1/2/3 Speed [xxxxRPM]
or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the CPU
fan, chassis fan, power fan, and optional fan speed in rotations per minute
(RPM). If any of the fans is not connected to the motherboard, the field shows
0. These items are not user-configurable.

Fan Speed Control

CPU Q-Fan Control
Chassis Q-Fan Control
POWER FAN Control
OPTFan1 Control
OPTFan2 Control
OPTFan3 Control
CPU Q-Fan Control [Disabled]
Allows you to enable or disable the CPU Q-fan control feature.
Configuration options: [Disabled] [Enabled]
The following item appears when you enable CPU Q-Fan Control.
CPU Fan Profile [Standard]
Allows you to set the appropriate performance level of the ASUS Q-Fan. When
set to [Standard], the CPU fan automatically adjusts depending on the CPU
temperature. Set this item to [Silent] to minimize fan speed for quiet CPU fan
operation, or [Turbo] to achieve maximum CPU fan speed. Configuration options:
[Standard] [Silent] [Turbo]
3-36
[Disabled]
[Disabled]
[Disabled]
[Disabled] [Disabled]
[Disabled]
[Disabled]
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
CPU Q-Fan Control
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Chapter 4: BIOS setup
