3.2.1

BIOS menu screen

Menu items

Menu bar

Extreme Tweaker
System Time
System Date
Legacy Diskette A
Language
SATA 1
SATA 2 SATA 2
SATA 3 SATA 3
SATA 4 SATA 4
SATA 5 SATA 5
SATA 6
SATA Coniguration
System Information
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Sub-menu items
3.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Extreme Tweaker For changing the overclocking settings
Main
Advanced
Power
Boot
Tools
Exit
To select an item on the menu bar, press the right or left arrow key on the keyboard
until the desired item is highlighted.
3.2.3

Navigation keys

At the bottom right corner of a menu screen are the navigation keys for that
particular menu. Use the navigation keys to select items in the menu and change
the settings.
Some of the navigation keys differ from one screen to another.
ASUS Maximus II Formula
Configuration fields
BIOS SETUP UTILITY
Main Advanced
[10:55:25]
[Thu 05/06/2008]
[1.44M, 3.5 in]
[English]
[Not Detected]
[Not Detected] [Not Detected] [Not Detected]
[Not Detected] [Not Detected] [Not Detected]
[Not Detected] [Not Detected] [Not Detected]
[Not Detected] [Not Detected] [Not Detected]
[Not Detected]
For changing the basic system configuration
For changing the advanced system settings
For changing the advanced power management (APM)
configuration
For changing the system boot configuration
For Configuring options for special functions
For selecting the exit options and loading default
settings
Power Boot Tools
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.
Use [+] or [-] to
configure system Time.
+-
Tab
F1
F10
ESC
General help
Exit
Select Screen
Select Item
Change Field
Select Field
General Help
Save and Exit
Exit
Navigation keys
3-9
