Layout contents

Connectors/Jumpers/Slots
1. CPU, chassis, and power fan connectors (4-pin CPU_FAN;
3-pin CHA_FAN1–3; 3-pin PWR_FAN; 3-pin OPT_FAN1–3)
2. ATX power connectors (24-pin EATXPWR, 8-pin ATX12V)
3. LGA775 CPU Socket
4. DDR2 DIMM slots
5. Chassis intrusion connector (4-1 pin CHASSIS)
6. Floppy disk drive connector (34-1 pin FLOPPY)
7. IDE connector (40-1 pin PRI_EIDE)
8. ICH10R Serial ATA RAID connectors (7-pin SATA1–6 [blue])
9. SIL5723 Serial ATA connectors (7-pin SPEEDING HDD1/2 [black])
10. Clear RTC RAM (3-pin CLRTC_SW)
11. System panel connector (20-8 pin PANEL)
12. USB connectors (10-1 pin USB78; USB910; USB1112)
13. BIOS flash setting (6-pin BIOS_FLASHBACK)
14. Power-on switch
15. Reset switch
16. Thermal sensor cable connectors (2-pin OPT_TEMP1–3)
17. IEEE 1394a port connector (10-1 pin IE1394_2)
18. ROG connector (2-pin ROG)
Refer to 2.7 Connectors for more information about rear panel connectors and
internal connectors.
