Main Panel
The Main Panel displays all the features and functions your SupremeFX X-Fi audio
card supports. Click each icon to configure the following settings (from left to right):
Speakers and Headphone, EAX Effects, X-Fi CMSS-3D, X-Fi Crystalizer, Smart
Volume Management, Graphic Equalizer, and Mixer.
Click each icon to
configure further
settings

Speakers and Headphone Panel

This panel allows you to configure speakers/headphone settings including bass
management and speaker volume. You can also test each speaker channel.
Click to select a
speaker type
Click to adjust bass
Click to adjust
volume of each
speaker
ASUS Maximus II Formula
Drag to adjust volume
Click to mute volume
Minimize
Exit
Help
Click to restore
default settings
Click to test speaker
sound in turn
Click to test speaker
noise in turn
4-13
