FSB/CPU External Frequency Synchronization
Front Side Bus
CPU External Frequency
FSB Strap to North Bridge [Auto]
Configuration options: [Auto] [200MHz] [266MHz] [333MHz] [400MHz]
DRAM Frequency [Auto]
Allows you to set the DDR2 operating frequency.
Configuration options: [Auto] [DDR2-667MHz] [DDR2-800MHz] [DDR2-835MHz]
[DDR2-887MHz] [DDR2-1002 MHz] [DDR2-1066MHz] [DDR2-1111MHz] [DDR2-1002 MHz] [DDR2-1066MHz] [DDR2-1111MHz]
[DDR2-*1200MHz*]
The DDR2 frequency reaches 1200 MHz after overclocking.
A very high DRAM frequency may cause the system to become unstable! If this
happens, revert to the default setting.
The configuration options may vary depending on the CPU level you select.
DRAM Command Rate [Auto]
Select [1N] to obtain better DRAM performance; select [2N] to enhance DRAM
overclocking ability. Configuration options: [Auto] [1N] [2N]
DRAM CLK Skew on Channel A1/A2/B1/B2 [Auto]
Configuration options: [Auto] [Advance 350ps] [Advance 300ps] [Advance 250ps]
[Advance 200ps] [Advance 150ps] [Advance 100ps] [Advance 50ps] [Normal]
[Delay 50ps] [Delay 100ps] [Delay 150ps] [Delay 200ps] [Delay 250ps]
[Delay 300ps] [Delay 350ps]
DRAM Timing Control [Auto]
Configuration options: [Auto] [
The following items become configurable when you set DRAM Timing Control
to [Manual].
1st Information : 5-5-5-15-3-44-5-3 (These values are auto-detected)
CAS# Latency [5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks]–[11 DRAM Clocks]
DRAM RAS# to CAS# Delay [5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks]–[18 DRAM Clocks]
ASUS Maximus II Formula
FSB 1600 FSB 1333
400 MHz 333 MHz
[DDR2-667MHz] [DDR2-800MHz] [DDR2-835MHz]
[DDR2-1066MHz] [DDR2-1111MHz]
]
Manual
FSB 1066 FSB 800
266 MHz 200 MHz
[DDR2-835MHz]
–[18 DRAM Clocks] [18 DRAM Clocks]
3-13
