Power On By PS/2 Keyboard [Disabled]
Allows you to disable the Power On by PS/2 keyboard function or set specific keys
on the PS/2 keyboard to turn on the system. This feature requires an ATX power
supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Space Bar] [Ctrl-Esc] [Power Key]
Energy Star 4.0c Support [Disabled]
Setting this item to [Enabled] to pass Energy Star 4.0c rating. When enabled,
S3-PS/2 & USB wake-up functions will be closed, and S4/S5-Marvell LAN, PS/2 &
USB devices wake-up functions will be closed.
Configuration options: [Enabled] [Disabled]
3.6.6

Hardware Monitor

Hardware Monitor
Voltage Monitor
Temperature Monitor
Fan Speed Monitor
Fan Speed Control
Voltage Monitor
CPU Voltage; DRAM Voltage; North Bridge 1.1 Voltage; CPU PLL Voltage;
South Bridge 1.1 Voltage; South Bridge 1.5 Voltage; FSB Termination
Voltage; DRAM VTT Voltage; 3.3V Voltage; 5V Voltage; 12V Voltage
The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators.
Temperature Monitor
CPU Temperature; NB Temperature; SB Temperature; MB Temperature;
POWER Temperature; OPT FAN1/2/3 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU,
northbridge, southbridge, motherboard, power, and the assigned devices
temperatures. Select [Ignored] if you do not wish to display the detected
temperatures.
NB overheat protection; SB overheat protection [90ºC]
The system automatically shuts down when the northbridge or southbridge
chipset is heated over the set temperature to protect it from damage.
Configuration optitons: [Disabled] [70ºC] [80ºC] [90ºC]
ASUS Maximus II Formula
BIOS SETUP UTILITY
Power
Voltage Monitor
