Chapter 2
Adapter
Configuration
Menu Menu
Server
Selector
Physical
Drives
Figure 2-1. HP NetRAID Assistant Main Window
The HP NetRAID Assistant window contains the following elements:
Menu bar: The menu bar activates pull-down menus for Configuration,
Adapter, Physical Drives, Logical Drives, Progress, and Help.
Toolbar: The toolbar icons, which are shown in Figure 2-2, are separated
into four categories of functions: Configuration, Properties, Miscellaneous,
and Other. They provide shortcuts to access the menu options.
Display
Print
Wizard
Clear
CONFIGURATION
Figure 2-2. HP NetRAID Assistant Main Menu Toolbar Options
16
Physical Logical
Progress
Drive Drive Menu
Menu Menu
Adapter Selector
Adapter
Rebuild Rate
Physical Drv
Logical Drv
PROPERTIES MISCELLANEOUS
HP NetRAID Assistant
Help
Menu
Toggle
Between
Views
Exit
Rescan
Help
View Log
OTHER
