Chapter 6
I. Connect Disk Drives to HP NetRAID
Connect physical drives to the HP NetRAID Series adapter or integrated
HP NetRAID controller. For example, you might have four drives of 4 GB each
connected to the HP NetRAID Series adapter.
II. Configure HP NetRAID
NOTE The Online Capacity Expansion feature is supported only on
arrays that contain just one logical drive each.
Configure your HP NetRAID Series adapter or integrated HP NetRAID controller
and create your logical drives. (This can be done in either HP NetRAID Config or
in HP NetRAID Express Tools. See Chapter 3, "HP NetRAID Config," or
Chapter 4, "HP NetRAID Express Tools," for complete instructions.) Save your
configuration and initialize your logical drives.
NOTE
It is important to initialize your logical drives. If the drives
have been previously configured under an operating system,
there can sometimes be residual partition/format information
which subsequently causes misrepresentation of logical drives
under the NetWare 4.2 Install module.
For example, your array of four drives (of 4 GB each) might be configured as a
single RAID 5 logical drive. This produces a logical drive of 12 GB of real
storage capacity, with 4 GB used for parity.
III. Enable Virtual Sizing
1. Restart the host HP NetServer, and watch for the message:
Option: Experienced users may press <Ctrl> <M> for
HP NetRAID Express Tools now.
Firmware Initializing
2. When the message is displayed, press <Ctrl> <M>. When the system stops
scanning, HP NetRAID Express Tools starts and displays the Tools
Management menu.
3. If you have installed one or more HP NetRAID Series adapters, do the
following to select the integrated controller or adapter controlling a logical
drive you want to prepare for expansion:
a. Choose Adapter from the Tools Management menu.
b. Choose the adapter controlling the logical drive.
Capacity Expansion
111
