SmartStep 2 –
the right step forward...
Omron knows that simplicity and precision are
vital in your positioning application.
The new SmartStep offers an ideal solution for
point-to-point motion applications where
simplicity is essential. SmartStep 2 keeps things
simple whilst combining high performance
in a cost-effective solution.
SmartStep 2 has a completely new compact
design that gives a 50% space saving compared
with the previous model. It also has new
features and functionality to help you to make
your machines more efficient and cost-effective.
Features at a glance:
Pulse control servo drive
•
Ultra-compact size
•
Auto-tuning
•
Vibration suppression
•
Adaptive resonance suppression filter
•
Two programmable torque limits
•
Feedback pulse output
•
Power range from 50 W to 750 W
•
Cylindrical and flat servo motors
•
Electronic gear
•
10,000 steps per revolution
•
...to faster development with great drive simplicity
Getting started quickly
CX-Drive is a single, easy-to-use software tool for configuring,
commissioning and maintaining both inverters and servos.
SmartStep 2 is fully supported with a wide range of features making
the servo drive set-up easier and faster than ever:
Auto-tuning
•
Parameter editing and monitoring
•
Speed and position diagrams
•
I/O status and alarms
•
Real-time data trace
•
Real-time data trace
Frequency analysis
