Creating Documents

4-11 Creating Documents

1,2,3...
Note
62
Project and screen settings and functional object property settings can be out-
put to RTF files by using the CX-Designer print function.
Screen images can also be output to bmp and jpg files.
The CX-Designer print function facilitates the production of a variety of docu-
ments, e.g., these files can be used as is for specifications, or the data can be
processed to create operation manuals, etc.
Procedure
1. Select File - Print.
2. When printing is executed, an RTF or bmp/jpg file is created.
(1) If Output to: is set to Printer, the settings will be output to the printer.
(2) If Output to: is set to File or Printer, header, footer, and margin settings
can be made.
Section 4-11
Outputs settings data
to RTF files.
Outputs screen images
to bmp and jpg files.
Select File to output
settings to an RTF file.
Select Image File to
output screen images
to a bmp or jpg file.
