Item
Fonts
Improved screen switching
function
Improved connection opera-
tions
SAP Library allocated unit
number and communications
setting information display
Programming Console function To use the Programming Console function
Bar codes
Test screens
DXF files
Initialization options for alarm/
event history data
Changing host settings with
the System Menu
Previous versions
Raster fonts could be set for objects with
changing display character strings, such as
numeric displays and inputs. Rounded
areas became rough, however, when the
font size was increased.
---
When serial ports A and B were both set for
use for NT Links, "Connecting" was dis-
played if either of the hosts was not con-
nected.
SAP Library settings could not be checked
even by displaying addresses using screen
data checking from the System Menu.
with the NS5-V2, it was necessary to copy
the program onto a Memory Card and to
insert the Memory Card into the NS5-V2.
The maximum length of data that could be
processed by an NS-series PT was 40
bytes.
---
DXF files could not be accessed.
When the alarm/event history data was
cleared by using $SB32, all history data
was cleared including current alarms or
events.
The settings of a host connected by Ether-
net or Controller Link could not be checked
with the System Menu.
New version
Scalable fonts have been added to enable
smooth displays. Gothic numeral and 7-
segment displays have also been added to
allow more attractive and up-to-date
screens to be created.
Speed and bitmap performance have been
improved for switching screens.
Even if one host is not connected, the mon-
itoring results of the connected host can be
displayed on the screen without "Connect-
ing" being displayed.
The following information can now be dis-
played.
• Command destination port names
• Destination network addresses
• Destination node addresses
• Destination unit numbers
• DeviceNet Slave Unit address and
Inverter node addresses
The Programming Console function is built-
in to the NS5-V2, so there is no need for a
Memory Card.
The maximum data length has been
increased to 254 bytes, allowing the data to
be processed by two-dimensional bar code
readers.
The following functions have been added to
test screens.
• Zoom
• Always displaying on top
• Starting test screens in the previous dis-
play position and zoom status
It is now possible to convert DXF files to
graphics and position them with the CX-
Designer.
System Memory $SW40 has been added
so that it is now possible to specify initializ-
ing cleared or confirmed history data.
A list of hosts can now be displayed by
selecting Communications Settings from
the System Menu. It is now also possible to
change the host network address, node
address, and host type.
xiii
