Transferring Only Edited Data to PT

4-10 Transferring Only Edited Data to PT

1,2,3...
Note
Macro details can be checked
on the Property List.
The data is edited and transferred to the PT many times when debugging
projects.
The CX-Designer has a Quick Transfer function. The Quick Transfer function
automatically compares project data with the data already transferred to the
PT and transfers only changed data.
This means that only the required data is transferred to the PT, which greatly
reduces the time and work required for transfers.
Date updated
Screen
2005/6/19 09:55
Screen 1
2005/6/19 10:00
Screen 2
2005/6/19 10:05
Screen 3
2005/6/19 09:55
Screen 4
:
Procedure
1. Select PT - Transfer - Quick Transfer [Computer → PT].
2. A dialog box to confirm the transfer will be displayed. Press the Yes Button
to start transferring the data.
(1) Transfer routes and other settings need to be made before executing
Quick Transfer. Select PT - Transfer - Transfer Setting to make the set-
tings.
(2) Select PT - Transfer - Transfer [Computer → PT] to transfer data for the
whole project to the PT.
Section 4-10
Select a functional
object in the Output
Window to select that
object on the screen.
A list of macro
locations will be
displayed.
Date updated
Screen
Screen 1
2005/6/19 09:55
Screen 2 2005/6/19 09:55
Screen 3 2005/6/19 09:55
Screen 4 2005/6/19 09:55
:
Only changed screens 2
and 3 are automatically
selected and transferred.
61
