Menu Commands
View Menu
30
Command
Toolbar Displays and hides the toolbar.
Window
Project Displays and hides the project workspace.
Workspace
Symbol Table Displays and hides the symbol table.
Property List Displays and hides the property list.
Library Displays and hides the Library Window.
Select Object Displays and hides the object selection.
Address in Use Displays and hides the List Up Addresses
List Used Window.
Output Window Displays and hides the Output Window.
Status Bar Displays and hides the Status Bar.
Previous Label Displays the previous label.
Next Label Displays the next label.
Previous Screen Displays the previous screen.
Next Screen Displays the next screen.
Previous Frame Displays the previous frame page.
Page
Next Frame Page Displays the next frame page.
Show Address
Show Symbol Switches to functional object display showing
Name symbol names.
Show Address Switches to functional object display showing
addresses.
Show I/O Switches to functional object display showing
Comment I/O comments.
Hide Switches to functional object display hiding
addresses.
Show ID Displays and hides ID numbers for objects.
Simulate ON/OFF Switches ON and OFF display for functional
objects.
Show Sheet Object Displays and hides objects registered in
sheets.
Grid Sets the grid.
Show Touch Points Displays and hides PT touch points.
Zoom Zooms the display in and out.
Refresh Redraws the screen.
Function
Section 3-2
Shortcut keys
---
Alt+1
Alt+2
Alt+3
Alt+4
Alt+5
Alt+6
Alt+7
---
Ctrl+PgUp
Ctrl+PgDn
Shift+PgUp
Shift+PgDn
PgUp
PgDn
---
---
---
---
---
---
---
---
---
---
F9
