Basic Operation Procedures
6
Copy symbols from the CX-Programmer Symbol
Table as required.
Make Project System Settings.
Select System Setting on the project workspace System Tab Page.
Alternatively, select PT - System Setting.
The address allocation settings for system memory
and the screen number to be displayed at startup are
set on the Initial Tab Page in the System Setting
Dialog Box.
Set the project properties as required. Make settings
such as language selection and label settings for
when using the switch label function.
Select Project Properties on the project workspace
System Tab Page.
Alternatively, select PT - Project properties.
Set the screen properties as required. Set the screen
title, size, pop-up screen setting, background and
other settings.
Select PT - Screen/sheet properties.
Create New Screen.
Select File - New Screen.
Create Functional Objects.
Select the functional object from the toolbar. Move
the cursor to the screen and drag the cursor from
the start point to the end point of the functional object.
Select the functional object just placed on the screen
and make address and other settings from the
property list. (Select the host name and set the
address. The address can also be set by selecting a
symbol from the symbol table.)
Refer to 4-1 Creating Screens Using Symbols
for details.
Section 1-2
