Figure 2 Static Discharge Points - Northern Telecom Meridian Meridian 1 Installation Manual

6 Overview
553-3201-200 Standard 1.0 April 1993
Figure 2xxx
Static discharge points
Wrist strap
connection point
Wrist strap
connection point
CAUTION
Equipment damage
To avoid damage from static discharge, wear an
antistatic wrist strap when you work on AEM
equipment. If a wrist strap is not available,
regularly touch one of the bare metal strips in the
AEM.
Module
rear
Power supply slot
Module
front
Bare metal strip
Bare metal strip
