Table 15. Component Values for SE Clocking Topology
Reference
L0
L1
L2
L3
Lclkref
Rs
The following guidelines should also be followed for single-ended clock implementations:
BCLK must be routed through trace impedance of 55 Ω +/- 10%.
•
•
Use 4 mil wide traces.
•
Place all serial termination resistors within 0.50 inches to clock driver pins.
•
Place all other signals at least 20 mils from the clock traces.
•
All the termination resistors are rated at 1% accuracy.
•
Match processor 0 and processor 1 L1 lengths as close as possible (maximum delta of 0.20")
Note: The chipset may use a different clock reference level than the processor. This difference should be
considered when determining clock routing trace lengths.
26
Value
0.25" to 0.5" You may flood this area
Match processor 0 and processor 1 L1 lengths as close as
5" to 9"
possible (maximum delta of 0.20")
L1 – 1.2"
L1 – 0.6" L3 length may be adjusted depending on the clock chip vendor
0" – 1" Minimize this trace length
22 to 33 Ω
1% Tolerance
Notes
Design Guide
