Front View

Control Lamps
Keyboard
Connector for optional
paper cutter
(Not used in this printer model)
Print Unit
Front Door
Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
The front door is held by a snap-lock. Open the front door to view
the various parts on the printer's front.
Display
Refer to chapter 10 "Options" for information on possible optional
devices fitted on the printer's front.
Chapter 3 Installation
17
