Front View

Indicator lamps
Display window
Keyboard
Connector
for optional
cutter
Print mechanism
Front door
EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
At the front of the printer are the display window, the indicator
lamps, and the keyboard. These features allow the operator to
control and set up the printer manually.
The front door is held by a snap-lock. Open the front door to
view the various parts on the printer's front.
Refer to "Options" on page
optional devices fitted on the printer's front.
Front View
Chapter 2 — Installation
101, for information on possible
Side door
7
