GET TO KNOW YOUR PRINTER
LED Indicator Lamps
Display Window
Keyboard
Label Taken Sensor
Cutter Interface Connector
Memory Card Adapter
(option)
Front Door
The front door can be swung open
and removed from the hinges. It
can also be replaced by an
optional paper cutter unit.
Main Switch
Voltage Switch
Provision for Optional Interface Connectors
Display Contrast Adjustment
Serial Interface Connector "uart1:"
Mains Receptacle
Machine Sign
Upper External Paper Intake
Lower External Paper Intake
