Technical Data

Printing:
Print Technique
Printhead Resolution
Print Speed (max)
Print Width (max)
Print Length (max)
Media Width (max/min
Internal Paper Roll Diameter (max)
Paper Roll Core Diameter
Ribbon Length (max)
Ribbon Width (max)
Print Directions
Modes of Operation
Tear Off
Peel Off
Cut Off
Firmware
Operating System
Smooth Fonts
Built-in fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x D x H)
Weight (excluding media & options)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMMs
Real-Time Clock w. 4 kbit memory
Power Supply
Mains Voltage
PFC Regulation
Maximum Power Consumption
Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
Direct Thermal & Thermal Transfer
12 dots/mm (304.8 dots/inch)
100 – 225 mm/sec (4 – 8.85"/sec)
165.3 mm (6.49")
depends on DRAM memory size
168 mm (6.61")/76.2 mm (3.00")
205 mm (8")
38 – 40 mm (1.5"), with adapter 76 mm (3")
450 metres (1475 feet)
166 mm (6.54")
4
Yes
Optional
Optional
Intermec Fingerprint 7.12
TrueDoc and TrueType fonts
15
36
Intermec Shell 4.2
335 x 482 x 238 mm (13.1 x 19.0 x 9.4")
15 kgs (33 lbs)
+5 C – +40 C (+41 F – +104 F)
20 –80% non-condensing
32 bit RISC
1 – 3 (2 Mbytes each)
1 – 2 (4 Mbytes each)
Yes
>90 – <264 V AC, 45 – 65 Hz
IEC 61000-3-2
Continuous 175W; Peek 350W

Appendix 1

With internal rewinder
With cutter
incl Direct Protocol
UNICODE Latin fonts
Std. 1 x 2 Mbytes
Std. 1 x 4 Mbytes
10+ years life
95
