Communication Cables

Serial Interface

Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
The EasyCoder 601 XP has – as standard – one serial communica-
tion interface: RS 232C on "uart1:".
Protocol
Default setup:
Baudrate: 9600
Char. length 8 bits
Parity: None
Stop bits: 1
RTS/CTS Disabled
ENQ/ACK: Disabled
XON/XOFF: Disabled (both ways)
New Line: CR/LF
To change the serial interface settings, see chapter 7 "Setting Up
the Printer".
Interface Cable
Computer end: DB9 or DB 25 female connector (PC)
Printer end: DB25 female connector
Host
Signal DB-9 DB-25
1
RXD 2
TXD 3
CTS 8
RTS 7
GND 5
16
DSR 6 20
22
1
/. The external +5V is limited to 200 mA and is automatically turned
off at overload. It is intended to drive e.g. an external alphanumeric
keyboard connected to the RS 232C port.
EasyCoder 601 XP
Signal DB-25 DB-25
1
2 TXD
3 RXD
4 RTS
5 CTS
6 DSR
7 Signal GND
1
+ 5V
DTR
RI

Appendix 3

Host
Signal
1 1 shield
2 3 RXD
3 2 TXD
4 5 CTS
5 4 RTS
6 20 DTR
7 7 GND
16
20 6 DSR
22
105
