Configuring the Management Ethernet Interface
Table 4-6
Table 4-7 Management Ethernet Interface Names for Single-Shelf Systems
Management Interface
Cisco CRS-1 RP in slot RP0
Cisco CRS-1 RP in slot RP1
Cisco CRS-1 DRP CPU0 in slot 5
Cisco CRS-1 DRP CPU1 in slot 5
Cisco XR 12000 Series Router PRP
in slot 0, port ETH0
Cisco XR 12000 Series Router PRP
in slot 0, port ETH1
Cisco XR 12000 Series Router PRP
in slot 1, port ETH0
Cisco XR 12000 Series Router PRP
in slot 1, port ETH1

Displaying the Available Management Ethernet Interfaces

To display the router interfaces, enter the show interfaces brief command in EXEC mode as follows:
RP/0/0/CPU0:router# show interfaces brief
--------------------------------------------------------------------------------
.
.
.
The Management Ethernet interfaces are listed with the prefix Mg in the Intf Name column.
Cisco IOS XR Getting Started Guide
4-40
provides examples of Management Ethernet interface names for a single-shelf system.
Interface Name
MgmtEth0/RP0/CPU0/0
MgmtEth0/RP1/CPU0/0
MgmtEth0/5/CPU0/0
MgmtEth0/5/CPU1/0
MgmtEth0/0/CPU0/0
MgmtEth0/0/CPU0/1
MgmtEth0/1/CPU0/0
MgmtEth0/1/CPU0/1
Intf Intf
Name State
Nu0
Mg0/0/CPU0/0
Mg0/0/CPU0/1 admin-down
PO0/3/0/0 admin-down
PO0/3/0/1 admin-down
PO0/3/0/2 admin-down
PO0/3/0/3 admin-down
PO0/3/0/4 admin-down
PO0/3/0/5 admin-down
PO0/3/0/6 admin-down
PO0/3/0/7 admin-down
Example
router(config)# interface MgmtEth0/RP0/CPU0/0
router(config)# interface MgmtEth0/RP1/CPU0/0
router(config)# interface MgmtEth0/5/CPU0/0
router(config)# interface MgmtEth0/5/CPU1/0
router(config)# interface MgmtEth0/0/CPU0/0
router(config)# interface MgmtEth0/0/CPU0/1
router(config)# interface MgmtEth0/1/CPU0/0
router(config)# interface MgmtEth0/1/CPU0/1
LineP
State
up up
up up
admin-down
admin-down
admin-down
admin-down
admin-down
admin-down
admin-down
admin-down
admin-down
Chapter 4 Configuring General Router Features
Encap MTU BW
Type (byte) (Kbps)
Null 1500 Unknown
ARPA 1514 100000
ARPA 1514 10000
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
HDLC 4474 155520
OL-10957-02
