Bringing Up and Configuring Rack 0
Command or Action
Step 7
dsc serial serial ID rack rackNumber
Example:
RP/0/RP0/CPU0:router(admin-config)# dsc
serial TBA00000002 rack 1
Step 8
dsc serial serial ID rack F n
Example:
RP/0/RP0/CPU0:router(admin-config)# dsc
serial TBA00000003 rack F0
Step 9
commit
Example:
RP/0/RP0/CPU0:router(admin-config)# commit
Step 10
show running-config | include dsc
Example:
RP/0/RP0/CPU0:router(admin-config)# show
running-config | include dsc
Cisco IOS XR Getting Started Guide
3-30
Chapter 3 Bringing Up the Cisco IOS XR Software on a Multishelf System
Purpose
Defines the rack number for the second LCC.
See the "Preparing a Rack Number Plan" section on
•
page 3-3 for information on locating the serial numbers
and selecting rack numbers.
Replace serial ID with the serial number of the second
•
LCC.
Replace rackNumber with a number in the range of 1 to
•
255.
When each subsequent LCC comes on line, the DSC
•
examines the chassis serial number and automatically
assigns the correct rack number to that chassis.
Defines the rack number for an FCC.
See the "Preparing a Rack Number Plan" section on
•
page 3-3 for information on locating the serial numbers
and selecting rack numbers.
Enter this command for every FCC in the multishelf
•
system.
Replace serial ID with the serial number of the FCC.
•
Replace n with the FCC rack number. These numbers
•
begin with F0 and increment to F1, F2, and F3.
When each subsequent rack comes on line, the DSC
•
examines the chassis serial number and automatically
assigns the correct rack number to that chassis.
Commits the target configuration to the router running
configuration.
Displays the committed rack number configuration. Verify
that the serial numbers entered for each chassis are correct.
