Summary of Contents for Delta Electronics AC Drive VFD-F Series

  • Page 4 480V for 460V models) and the mains supply current capacity must be ≤ 5000A RMS (≤10000A RMS for the ≥ 40hp (30kW) models) CAUTION! Heat sink may heat up over 70 the heat sink. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED WARNING C (158 F), during the operation. Do not touch...

  • Page 5: Table Of Contents

    4.1.1 Description of the Digital Keypad VFD-PU01 ... 4 - 2 4.1.2 Explanation of Display Message... 4 - 2 4.1.3 Operation Steps of the Digital Keypad VFD-PU01 ... 4 - 4 TABLE OF CONTENTS DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 6: Table Of Contents

    5.12 Group 11: Fan and Pump Control Parameters... 5-63 CHAPTER 6 MAINTENANCE AND INSPECTIONS 6.1 Periodic Inspection ... 6 - 1 6.2 Periodic Maintenance ... 6 - 1 CHAPTER 7 TROUBLESHOOTING AND FAULT INFORMATION... 7 - 1 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED VFD-F Series...

  • Page 7: Table Of Contents

    B.6.1 Description of the Digital Keypad VFD-PU06... B-14 B.6.2 Explanation of Display Message ... B-14 B.6.3 PU06 Operation Flow Chart ... B-15 B.7 Relay Card ... B-16 B.8 Zero Phase Reactor ... B-18 APPENDIX C DIMENSIONS... C - 1 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 8: Receiving And Inspections

    015: 2.0HP(1.5kW) 022: 3.0HP(2.2kW) 037: 5.0HP(3.7kW) 055: 7.5HP(5.5kW) 075: 10 HP(7.5kW) 110: 15 HP(11kW) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Example for 7.5HP/5.5kW 3-phase 460V AC drive MODEL : VFD055F43A INPUT : 3PH 380-480V 50/60Hz 14A OUTPUT : 3PH 0-480V 13 Frequency Range : 1.5-120Hz...

  • Page 9: Series Number Explanation

    VFD-F Series 1.3 Series Number Explanation 055F43A Production number 460V 3-PHASE 7.5HP(5.5kW) Production model If there is any nameplate information not corresponding to your purchase order or any problem, please contact your distributor. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 10: Storage And Installation

    Atmosphere pressure: 86 to 106 kPa Vibration: Maximum 9.86 m/s (0.6G) at 20Hz to 50Hz Pollution Degree 2: good for a factory type environment. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED C to +40 C (14 F to 104 C (122 F) without dust cover.
  • Page 11 Mount the AC drive vertically and do not restrict the air flow to the heat sink fins. The AC drive generates heat. Allow sufficient space around the unit for heat dissipation. 150mm CAUTION VFD-F VFD-PU 01 STOP JO G STO P RESET 150mm Air Flow DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 12: Wiring

    Wait five minutes for DC bus capacitors discharge. Any electrical or mechanical modification to this equipment without prior written consent of Delta Electronics, Inc. will void all warranties and may result in a safety hazard in addition to voiding the UL listing.

  • Page 13: Basic Wiring Diagram

    Multi-function analog output terminals AFM1 Factory setting: output frequency 0~10Vdc/2mA AFM2 Factory setting: output current 0~20mA/4~20mA Max. Impedance: Analog Signal Common RY00 Optional Relay B.D. Main circuit (power) terminals Control circuit terminals Shielded leads&cable DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 500Ω...
  • Page 14 Factory Setting Accel/Decel Prohibit 1/2 Accel/Decel Switch Digital Signal Common NO TE Don't apply the mains voltage directly to above terminals. 0-5V 0-10V DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Brake Unit (Optional) VFDB U(T1) R(L1) S(L2) V(T2) T(L3) W(T3) AFM1...
  • Page 15 VFD-F Series Wiring for SINK mode and SOURCE mode Source 1/2 Accel/Decel switch Sink 1/2 Accel/Decel switch DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 16: External Wiring

    R/L1 S/L2 T/L3 +/B1 U/T1 V/T2 W/T3 Zero-phase Reactor Output AC Line Reactor Motor DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Items Explanations Please follow the specific power Power supply requirements shown in supply Appendix A. There may be an inrush current during power up.

  • Page 17: Main Circuit Connection

    Connections for External Brake Unit (VFDB series) Earth Ground Brake Resistor (Optional) +1 +2/B1 R(L1) S(L2) T(L3) VFDB R(L1) S(L2) T(L3) Explanation of Terminal Function DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Motor U(T1) V(T2) W(T3) Brake Resistor (Optional) Motor U(T1) V(T2) W(T3)
  • Page 18 Terminals [+1, +2] for connecting DC reactor To improve power factor and reduce harmonics, connect a DC reactor between terminals [+1, +2]. Please remove the jumper before connecting the DC reactor. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED DC reactor Jumper...
  • Page 19 Short-circuiting [B2] or [-] to [+2/B1] can damage the AC motor drive. Br ak e res istor(optional) Br ak e unit(optional ) VFDB Refer to Appendix B for the us e of special brake resis tor /unit +2/ B1 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 20: Control Terminals

    RA 2 output (N.O.) a Multi-function Relay2 RB 2 output (N.C.) b Multi-function Relay2 RC 2 common DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED SOURCE/PNP Mode Multi-function Input Terminal Internal Circuit +24V Factory Settings Factory setting: Multi-step speed command 1 Factory setting: Multi-step speed command 2...
  • Page 21 0 to +10V correspond to Max. operation frequency 4 to 20mA correspond to Max. operation frequency 0 to 10V correspond to Max. operation frequency 4 to 20mA correspond to 2 times of output current ACI1/ACI2 ferrite core 3-10 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 22: Specifications For Power Terminals And Control Terminals

    U/T1 V/T2 W/T3 Screw Torque : 18Kgf-cm Wire Gauge : 18~10AWG R/L1 S/L2 T/L3 Frame C POWER MOTOR DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Power Terminals: R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, Models Wire Gauge VFD007F23A VFD007F43A VFD007F43H VFD015F23A VFD015F43A VFD015F43H 12-24 AWG.
  • Page 23 VFD450F43A 2 AWG. (33.6mm VFD450F43H VFD550F43A 1/0-4/0 AWG. (53.5-107.2mm VFD550F43H Control Terminals: Wire Gauge 12-24AWG. (3.3-0.2mm 3-12 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED , +1, +2, -, Torque Wire Type Stranded 30kgf-cm Copper only, (26in-lbf) 75℃ Torque 4kgf-cm (3in-lbf) , +1, +2, -,...
  • Page 24 Frame H R/L1 S/L2 T/L3 U/T1 V/T2 W/T3 DC + DC ( ) - POWER DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Power Terminals: R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, Models Wire Gauge VFD1100F43C VFD1100F43H VFD1320F43A 4/0 AWG. - 300MCM (107.2-152mm...
  • Page 25 10. Do not attach or remove wiring when power is applied to the AC drive. 11. Do not inspect components unless inside “CHARGE” lamp is turned off. 12. Do not monitor the signals on the circuit board while the AC drive is in operation. 3-14 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Forward running...
  • Page 26 19. There are highly sensitive MOS components on the printed circuit boards. These components are especially sensitive to static electricity. To prevent damage to these components, do not touch these components or the circuit boards with metal objects or your bare hands. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 3-15 VFD-F Series...

  • Page 27: Motor Operation Precautions

    3. When the standard motor operates at low speed, the output load must be decreased. 4. If 100% output torque is desired at low speed, it may be necessary to use a special “inverter-duty” rated motor. 3-16 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 28: Digital Keypad Operation

    Description of the Keypad Description of Display Keypad Operation Modes & Programming Steps DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED VFD-F Series...

  • Page 29: Description Of The Digital Keypad Vfd-Pu

    Display the output current present at terminals U/T1, V/T2, and W/T3. LED Display Display frequency, current, voltage and error, etc. Part Number Status Display Display the driver's current status MODE hanges between different display mode. STOP/RESET RUN key Descriptions DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 30 Display Message DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Descriptions Display the AC drive forward run status. The AC drive reverse run status. Display the specified parameter setting. Display the actual value stored within the specified parameter. External Fault. Display “End” for approximately 1 second if input has been accepted.

  • Page 31: Operation Steps Of The Digital Keypad Vfd-Pu

    To modify data START Setting direction MODE MODE to set the parameters. move to previous display MODE MODE MODE Success to set parameter. Input data error to return the selecting mode. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED MODE GO START...

  • Page 32: Kpf-Cc01

    4.2.2 Explanation of Display Message Display Message The AC motor drive Master Frequency Command. The Actual Operation Frequency present at terminals U, V, W. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED LCD Display Indicates frequency, voltage, current, user defined units, read, and save etc.

  • Page 33: Kpf-Cc01 Operation Flow Chart

    Use UP/DOWN key to confirm copy function. Press PROG/DATA key to execute. External Fault. Input data is accepted. Input data is invalid. 4.2.3 KPF-CC01 Operation Flow Chart KPF-CC01 Operation Flow Chart DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 34: Group 0: Ac Drive Status Parameters

    20 codE 21 EF1 (external emergency stop) 22 PHL (phase loss) 23 Lc (Low Current) 24 FbL(Feedback Loss) 25 Reserved DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory setting: Read Only Factory setting: Read Only Explanation over current over voltage over temperature...
  • Page 35 Fan 2, 3 Fault Gate Drive Low Voltage Protect Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 36 When User Target Value <=99.99, 00-13=0. 00 - 14 PLC time This parameter displays remaining time of PLC each phase. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only Factory setting: Read Only...

  • Page 37: Group 1: Basic Parameters

    This parameter sets the Mid-point Frequency of the V/f curve. This parameter must meet the following argument. Pr.1-01 >= Pr.1-03 >= Pr.1-05. Factory Setting: 60.00 Factory Setting: 60.00 Factory Setting: 220.0/440.0 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 1.50...
  • Page 38 The Lower Bound Frequency setting must be smaller than the Dwell Frequency (Pr.11-08>=01-08). If lower bound frequency setting is greater than the Dwell Frequency, the AC drive will equalize the two settings to the Lower Bound point. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 5.5/11.0 Factory Setting: 1.50 Factory Setting: 5.5/11.0...
  • Page 39 You can set 1 to 4 Accel/Decel time via multi-function input terminals 04-00 to 04-07. 01-03 01-01 01-00 01-07 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Output Frequency Factory Setting: 10.0/60.0 Factory Setting: 10.0/60.0 Factory Setting: 10.0/60.0 Factory Setting: 10.0/60.0 Factory Setting: 10.0/60.0 Factory Setting: 10.0/60.0...
  • Page 40 02: Unit is 0.01 Sec This parameter sets the resolution of accel/decel time (Pr.01-09 to 01-18). A high resolution decreases the accel/decel time range as shown in the following chart. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 6.00 Factory Setting: 0.00 Factory Setting: 1.00...
  • Page 41 VFD-F Series 01-23 Accel/Decel time unit Accel/Decel time range 1 Sec 1~36000 Sec 0.1 Sec 0.1~3600.0 Sec 0.01 Sec 0.01~360.00 Sec DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 42: Group 2: Operation Method Parameters

    This parameter sets the operation command source of the AC drive. When the AC drive is controlled by an external source, you may select 2-wire or 3-wire operation. Please refer to Pr.02-05. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 Factory Setting: 00...
  • Page 43 Motor Speed Time Stops according Operation to deceleration Command time STOP 5-10 Factory Setting: 00 Frequency Free running to stop Coast Factory Setting: 9000Hz Factory Setting: 6000Hz Factory Setting: 4000Hz DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Time STOP Unit: 1...
  • Page 44 Please refer to 02-01. 02-05 00 (2-wire #1) FWD / STOP REV / STOP 01 (2-wire #2) RUN / STOP REV / FWD 02 3-wire DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Electromagnetic Leakage Noise Current Signification Signification Minimal Minimal External Terminal :("OPEN":STOP)
  • Page 45 10 = U LED (special display) 11 = Fwd / Rev 001 = 2nd 7-step 010 = 3rd 7-step 011 = 4th 7-step 100 = 5th 7-step 5-12 Factory Setting: 01 Factory Setting: 01 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 46 02 - 13 Master Frequency Memory Setting Settings 00: Do not remember the last known frequency 01: Remember the last known frequency DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 Factory Setting: 1.00 Factory Setting: 00 Factory Setting: 00...
  • Page 47 Upon power up the last known frequency is displayed. After a fault, the AC drive will always remember the last know master frequency command. This feature is only enabled when Pr. 02-00 is set for 0 or 4. 5-14 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 48: Group 3: Output Function Parameters

    Auxiliary 7 output Indication during operation Master frequency attained Zero Speed (including shutdown) Over-torque External Fault DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 Factory Setting: 00 Factory Setting: 00 Factory Setting: 00 Factory Setting: 00 Factory Setting: 00...
  • Page 49 The Output will be activated for 0.5 sec when each multi-step speed is attained. The output will be activated for 0.5 sec when the PLC program cycle has completed The output will be activated when PLC operation is paused. 5-16 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 50 Setting 00: 0-10V = 0 - (Pr.01-00) Setting 01: 0-10V = 0 - (2.52.0 x rated current) Setting 02: 0-10V = 0 - (Pr.01-02) Setting 03: 0-10V = 0 - Master Freq. command DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Master frequency 1 Frequency...
  • Page 51 03: Fan is controlled by temperature. Approximately a 60°C temperature will start the fan. This parameter determines DC fan control method. STOP command. command 5-18 Factory Setting: 100 Factory Setting: 100 Factory Setting: 01 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 52: Group 4: Input Function Parameters

    B.B. (NO) input B.B. (NC) input Increase Frequency Decrease Frequency Emergency stop (NO) Emergency stop (NC) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 01 Factory Setting: 02 Factory Setting: 03 Factory Setting: 04 Factory Setting: 05 Factory Setting: 07...

  • Page 53: Setting Functions

    Input Terminal to enable the AC drive internal PLC program. Parameter value 33 programs an input terminal to pause the PLC program. Note: Pr.05-00 to Pr.05-16 defines the PLC program. 5-20 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 01...
  • Page 54 The above parameters are used to set the analog input reference values. The min and max frequencies are based on Pr.01-00 (during open-loop control) or the PID reference value Pr.10-01 (during PID close-loop control). DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 0.0 Factory Setting: 10.0 Factory Setting: 0.00...
  • Page 55 04-11=30 04-15=0 04-19=0 04-9=0V 04-17=0mA When analog input current of ACI1/ACI2 is lower than Pr.04-13/Pr.04-17, EF warning will pup-up. 04-09 04-10 04-13 04-14 04-17 04-18 ACI2 ACI1 04-18=10mA 04-13=4mA 5-22 Analog input Analog input DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 56 05: Communication master frequency +ACI1 06: Communication master frequency +ACI2 This parameter selects the terminals used for summation of the External Frequency Sources. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 0.50 Factory Setting: 0.50 Factory Setting: 0.50 Factory Setting: 00...

  • Page 57: Group 5: Multi-Step Speed Frequency Parameters

    Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 0.00 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Unit: 0.01...
  • Page 58 To stop the PLC program, one must either pause the program or turn it off. (Refer to Pr.04-00 to 04-07 values 32 and 33). DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED step speed (sets the frequency of each step speed)
  • Page 59 15 speed steps. The binary notation for the 15-bit number must be translated into decimal notation and then entered. PLC operation execution one cycle step by step 05-01 05-18 05-19 5-26 05-03 05-02 05-20 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Time...
  • Page 60 =16384+2048+1024+64+32+16+2 =19570 Setting 05-16 =19570 NOTE: 2 =16384 2 =8192 2 =512 2 =256 2 =16 2 =8 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 0=Forward 1=Reverse Direction of Direction of Direction of Direction of Direction of Direction of Direction of...
  • Page 61 Note: If a parameter is set to “00” (0 sec), the corresponding step will be skipped. This is commonly used to reduce the number of program steps. 5-28 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 0.0 Factory Setting: 0.0 Factory Setting: 0.0...
  • Page 62 Pr.04-00 to Pr.04-07 (MI1 to MI8 4) Jog Freq. 05 - 32 Time Unit Settings Settings 1 Sec 0.1 Sec This parameter determines the time unit for Pr.05-17~Pr.05-31. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 05-07 Frequency 05-06 05-08 05-05 05-04 05-03...
  • Page 63 When the over-current stall prevention is activated, the acceleration time of the AC drive will be longer than the time set in Pr. 01-09. Deceleration characteristic when Over-voltage stall prevention enabled Frequency held Deceleration Time 5-30 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 390.0/780.0 Time Factory Setting: 120 Unit: 1...
  • Page 64 02: Over-torque detection enabled during constant speed operation (OL2), and operation halted. 03: Over-torque detection enabled during operation (OL2), and operation continues. 04: Over-torque detection enabled during constant speed operation (OL2), and operation halted. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Current Output frequency Over-current stall prevention during...
  • Page 65 The common electronic thermal reaction time (150% output current for 1 minute) is shown in the chart below. The actual reaction time will vary depending on output current. 5-32 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 110 Unit: 1 Factory Setting: 0.1...
  • Page 66 Overheat (oH) Overload (oL) Electronic thermal relay (oL1) External fault (EF) AC drive IGBT fault (occ) CPU failure (cF3) Hardware protection failure (HPF) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 60Hz or more 50Hz 10Hz Load factor Factory Setting: 00 Factory Setting: 10.0...
  • Page 67 Fan 1, 2, 3 Fault (FF123) Fan 1, 2 Fault (FF12) Fan 1, 3 Fault (FF13) Fan 2, 3 Fault (FF23) Gate Drive Low Voltage Protect (Fv) 5-34 Factory Setting: 00 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 68 This parameter allows the user to set a password for parameter protection. After entering a password, Pr.6-17 will display 1. Be sure to keep the password in a safe place. If the password is lost, please return the drive to DELTA. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 5-35 VFD-F Series...

  • Page 69: Group 7: Ac Drive And Motor Parameters

    Pr.7-02 should be set to 80%. 10KHz 4KHz 9KHz 9KHz 3KHz 6KHz 5-36 Factory Setting: ## Factory Setting: ## 18.5 9KHz 3KHz 6KHz 110 130 160 185 220 6KHz 2KHz 4KHz Factory Setting: 100% DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 6KHz 2KHz 4KHz Unit: 1...
  • Page 70 Output frequency after compensation is limited by 01-07 upper bound frequency. When using slip compensation, 01-07 should be set to the suitable value. When PID feedback control, slip compensation function will be disabled. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 30% Factory Setting: 0.0...
  • Page 71 Calculate Total Running Time of the Motor (Day) Settings 00 to 65535 Day This parameter could display running time of the motor. 5-38 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 0.00 Unit: 0.01 Factory Setting: 0.0 Unit: 0.1 Factory Setting: 0.0 Unit: 1.0...

  • Page 72: Group 8: Special Parameters

    If this parameter is set greater than 01-05 minimum frequency setting, it won’t decelerate to 01-05 and enter DC brake status when AC drive brakes. Suitable DC brake start-up frequency setting will get better brake characteristic. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 Factory Setting: 0.0 Factory Setting: 0.0...
  • Page 73 DC braking Stop point for time during DC braking stopping time during Minimum stopping output 08-03 frequency 01-05 O FF DC Braking Time 5-40 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Time Factory Setting: 00 Factory Setting: 2.0 Unit: 0.1...
  • Page 74 08-05 Power Input Speed Search 08-04=01 B.B. Time Output 08-06 Frequency Output Voltage DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Max. Allowable Power Loss Time Speed Synchronization Detection Momentary Power Loss Operation 5-41 VFD-F Series Factory Setting: 0.5 Unit: 0.1 Factory Setting: 110...
  • Page 75 If fault occurred times exceed 08-09 setting, AC drive will reject to restart and need to reset by users to keep on running. Synchronization attained Actual V/F output V/F curve setting 5-42 Output frequency Output voltage output current Time Output frequency Factory Setting: 00 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 76 00: Energy-saving operation disabled Settings 01: Energy-saving operation enabled This parameter determines automatic energy-saving function. 100% DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Output voltage During the auto energy-saving operation, it will adjust the output voltage according to the output power. The maximum output voltage can be 30% lower than the normal output voltage.
  • Page 77 This parameter will minimize vibration at low speed during vector control. The value of the parameter is a GAIN. The higher the value, the more vibration dampening that will occur. Factory Setting: 380.0/ 5-44 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 760.0 Unit: 0.1...

  • Page 78: Group 9: Communication Parameters

    03: None parity + 1 stop bit 04: Even parity + 1 stop bit 05: Odd parity + 1 stop bit This parameter determines the communication format of serial communication. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 01 Factory Setting: 01 Factory Setting: 03...
  • Page 79 1011: 11 step speed 1100: 12 step speed 1101: 13 step speed 1110: 14 step speed 1111: 15 step speed 5-46 Factory Setting: 00 Factory Setting: 60.00 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Unit: 0.01...
  • Page 80 Each 8-bit is the combination of two 4-bit hexadecimal characters. For example, 64 Hex. 2. Data format 2.1 10-bit character frame ( for 7-bit ) : (7 , N , 2 : 9-04=0, 9-05=0) Start DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 1: EV 2: GND 3: SG- 4: SG+...
  • Page 81 10-bit character frame 7-bit character 10-bit character frame 8-bit character 11-bit character frame 8-bit character 11-bit character frame 8-bit character 11-bit character frame 5-48 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Stop Even parity Stop parity Stop Stop Even Stop parity...
  • Page 82 RTU mode: (ADR) = 10H 3.3 CMD (command code) and DATA (data character) The format of data characters depends on the command code. The available command codes are described as followed: DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 5-49 VFD-F Series...
  • Page 83 END 0 Response message: Number of data data 0101H content 0102H content CRC CHK LOW CRC CHK HIGH 5-50 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Error response message ‘:’ ADR 1 ‘0’ ADR 0 ‘1’ CMD 1 ‘8’ CMD 0 ‘3’...
  • Page 84 ‘1’ END 1 END 0 RTU mode: Command message: data Starting address data CRC CHK LOW CRC CHK HIGH C6H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Response message: ‘:’ ADR 1 ‘0’ ADR 0 ‘1’ CMD 1 ‘0’ CMD 0 ‘6’...
  • Page 85 END 0 Response message: CMD 1 data Starting address 00H data CRC CHK LOW EEH CRC CHK HIGH 1FH 5-52 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Error response message ‘:’ ADR 1 ‘0’ ADR 0 ‘1’ CMD 1 ‘8’ CMD 0 ‘8’...
  • Page 86 Number of data (Word) Number of data (Byte) The first data The second data CRC CHK LOW 4DH CRC CHK HIGH D9H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Response message: ‘:’ ‘:’ ‘0’ ADR 1 ‘0’ ‘1’ ADR 0 ‘1’...
  • Page 87 ‘1’ CMD 1 ‘0’ CMD 0 ‘3’ Data starting ‘0’ address ‘4’ ‘0’ ‘1’ Number of data ‘0’ ‘0’ ‘0’ ‘1’ LRC CHK 1 ‘F’ LRC CHK 0 ‘6’ END 1 END 0 5-54 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 88 ^= *data++; for(j=0;j<8;j++){ if(reg_crc & 0x01){ /* LSB(b0)=1 */ reg_crc=(reg_crc>>1) ^ 0xA001; }else{ reg_crc=reg_crc >>1; return reg_crc; DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Command message: Data starting address Number of data (word) CRC CHK Low CRC CHK High...
  • Page 89 08: CPU failure (cF3) 09: Hardware protection failure (HPF) 10: Over current during acceleration (ocA) 11: Over current during deceleration (ocd) 12: Over current during steady state operation (ocn) 13: Ground Fault (GFF) 5-56 Function DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 90 Bit 11 Bit 12 Bit 13 Bit 14-15 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Function 00: Run LED is off and STOP led is on. (AC Drive stopping) 01: RUN LED is blink and STOP led is on. (AC Drive deceleration to stop) 10: RUN LED is on and STOP led is blink.
  • Page 91 User Target Value (Low bit) uL 0-99.99 User Target Value (High bit) uH 0-9999 PLC time Reserved ‘:’ ‘0’ ‘1’ ‘8’ ‘6’ ‘0’ ‘2’ ‘7’ ‘7’ 5-58 Function RTU mode Address Function Exception code CRC CHK Low CRC CHK High DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 92 If Pr.09-03 is not equal to 0.0, Pr.09-02=00~02, and there is no communication on the bus during the Time-out detection period (set by Pr.09-03), “cE10” will be shown on the keypad. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 5-59 VFD-F Series...

  • Page 93: Group 10: Pid Control Parameters

    Difference Range 10-03 10-04 10-05 5-60 Factory Setting: 00 Primary Low Pass Upper FilterTime Bound for Integral Control Upper/Lower 10-06 bound Freq. 01-07/01-08 Frequency Command Factory Setting: 1000.0 Factory Setting: 00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 10-07 Unit: 0.1...
  • Page 94 10 - 07 Primary Low Pass Filter Time Settings 0.0~2.5 Sec This parameter determines primary Low Pass filter time. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 1.0 Factory Setting: 1.00 Factory Setting: 0.00 Factory Setting: 100 Factory Setting: 0.0...
  • Page 95 1 and 01-08 is 0, the output frequency is equal to the value of 01-05 setting. If it is set to 1 and 01-08 is not 0, the output frequency is equal to the value of 01-08 setting. Factory Setting: 600.0 5-62 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Unit:0.1 Factory Setting: 0.0 Unit: 0.1...

  • Page 96: Group 11: Fan And Pump Control Parameters

    02: Fixed amount circulation (by PID) 03: Fixed amount control (an AC drive runs with 4 motors) This parameter is to set an AC drive runs with multiple motors in circulation control mode. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Voltage% 1.5 power curve 1.7 power curve...
  • Page 97 Pr01-09 Pr11-04 Pr1 1-03 Pr11-04 Pr11-03 Pr11-04 by VFD-F by VFD- F Contactor Contactor Contactor Contactor 5-64 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED time Acc T ime Pr01-09 Pr01-09 Pr1 1-03 Pr1 1-04 Pr1 1-03 Pr11-04 by VFD-F by VFD-F...
  • Page 98 Previous routine repeats to 2nd motor→3rd motor→4th motor till VFD-F reaches proper PID values. VFD-F only runs PID control mode to last motor, others run full power. VFD-F RY00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED R S T Contactor Contactor...
  • Page 99 VFD-F only runs PID control mode to 1st motor, others run full power. VFD-F RY00 When this parameter isn’t set to 00, 03-00 to 03-07 multi-function terminals will automatically set the corresponding output motor. R S T Contactor Contactor Contactor Contactor 5-66 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 100 This parameter is to set running time of each motor (including acceleration time) when multiple motors are in time circulation mode (11-01=1). If this parameter is set to 00, time setting is disabled and run with a motor. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Motor 1 runs Motor 1 runs Motor 1 runs by AC drive.
  • Page 101 11-05. Suitable delay time setting will decrease motor switch times. 11-04 11-03 11-01 01 11-02 04 04-00 29 5-68 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED ＝ ＝ Motor 3 disable ＝ Factory Setting: 1.0 Unit: 0.1 Factory Setting: 10.0...
  • Page 102 T1: enter sleep process time (Pr.11-07) T2: motor switch delay time during fixed amount circulation (Pr.11-05) T3: motor switch delay time (Pr.11-04) N: motor 1 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Motor 1 frequency Output frequency of AC drive 11-05...
  • Page 103 Are there any motors that power supply is from commercial power? Away from commercial power in order T1 0 calculates Sleep Process calculates calculates F>(11-09) Fixed amount circulation control process 5-70 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Sleep Process ＝...
  • Page 104 01-05 minimum frequency setting according to V/f curve. The setting of wake up frequency needs to be greater than sleep frequency. Frequency 11-09 11-08 01-08 01-05 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Frequency command that calculates by PID Deceleration time limit 11-07 5-71 VFD-F Series Factory Setting: 0.0...
  • Page 105 If output frequency of AC drive is less than or equal to this parameter when AC drive is fixed amount circulation (11-01=02) sequence. or fixed amount (11-01=03) 5-72 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Setting: 00 Factory Setting: 0.00 Unit: 0.01Hz , AC drive will make motor stop in...

  • Page 106: Periodic Inspection

    Clean off any dust and dirt with a vacuum cleaner. Place special emphasis on cleaning the ventilation ports and PCBs. Always keep these areas clean, as accumulation of dust and dirt can cause unforeseen failures. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED VFD-F Series...
  • Page 107 VFD-F Series This page intentionally left blank. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 108: Chapter 7 Troubleshooting And Fault Information

    The AC drive detects that the DC bus voltage has exceeded its maximum allowable value. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Corrective Actions 1. Check whether the motors horsepower corresponds to the AC drive output power. 2. Check the wiring connections between the AC drive and motor for possible short circuits.
  • Page 109 Motor Rated Current Pr.7-00. 1. Reduce the motor load. 2. Adjust the over-torque detection setting to an appropriate setting (Pr.06-03 to Pr.06-05). Return to the factory. Return to the factory. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 110 2. Sudden increase in motor loading. 3. AC drive output capacity is too small. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Corrective Actions Return to the factory. Return to the factory. Return to the factory. 1. Check the connection between the AC drive and computer for loose wires.
  • Page 111 Return to the factory. Return to the factory. Return to the factory. Return to the factory. Return to the factory. Return to the factory. Return to the factory. Don’t use the function of auto acceleration /deceleration. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 112 Fan Power Fault (150~300HP) Fan 1 fault (150~300HP) Fan 2 fault (150~300HP) Fan 3 fault (150~300HP) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Corrective Actions Ground fault: 1. Check whether the IGBT power module is damaged. 2. Check for possible poor insulation at the output line.
  • Page 113 Remove any foreign objects on the heatsinks and check for possible dirty heat sink fins. Remove any foreign objects on the heatsinks and check for possible dirty heat sink fins. Return to the factory. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 114 Group 0 AC Drive Status Parameter Parameters Functions 00-00 Software Version 00-01 AC Drive Status Indication 1 00: No Fault occurred DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings Read only 01: oc (over current) 02: ov (over voltage) 03: oH (over temperature) 04: oL (overload)
  • Page 115 Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only Read only DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Customer Setting Read Read Read Read Read Read Read Read...
  • Page 116 S Curve Delay Time in Accel 0.00~2.50sec 01-21 S Curve Delay Time in Decel 0.00~2.50sec 01-22 Modulation Index 01-23 Accel/Decel Time Unit DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 0.10~120.00 Hz 230V series: 0.1~255.0V 460V series: 0.2~510.0V 0.10~120 Hz 230V series: 0.1~255.0V 460V series: 0.2~510.0V...
  • Page 117 15~30HP: 3000~9000Hz ≧40HP: 2000~6000Hz 00: Forward enabled 01: Reverse disabled 02: Forward disabled 00: 2-wire (#1), FWD/STOP, REV/STOP 01: 2-wire (#2), RUN/STOP, REV/FWD 02: 3-wire 00: Disabled 01: Enabled DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Customer Setting 9000Hz 6000Hz 4000Hz...
  • Page 118 02-11 Flying Start 02-12 Flying Start Frequency 02-13 Master Frequency Memory Setting DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 00: Decelerate to 0Hz 01: E.F. 02: Continue operation by the last frequency command Bit0~1: 00 = F LED 01 = H LED...
  • Page 119 30: OL or OL1 overload warning 31: Dwell indication (sleep) 32: Low current indication 33: PID feedback error indication 34: PLC program running 35: PLC program step completed 36: PLC program completed Factory Settings Setting DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 120 Analog Output Gain 1 03-13 Analog Output Gain 2 03-14 Analog Output 2 Selection (AFM2 Definition) 03-15 DC Fan Control DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 37: PLC program operation Paused 0.00~120.00 Hz 0.00~120.00 Hz 00: Output frequency 01: Output current...
  • Page 121 29: Motor No.3 output disable 30: Motor No.4 output disable 31: All motor output disable 32: Run PLC program 33: Pause PLC program 01~20 0.0~10.0V 0.0~10.0V 0.00~100.00% 0.00~100.00% 0.0~20.0mA 0.0~20.0mA Factory Settings Setting 10.0 0.00 100.00 20.0 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 122 (percentage of Pr.1-00) 04-21 Analog Input Delay AVI 04-22 Analog Input Delay ACI1 04-23 Analog Input Delay ACI2 04-24 Summation of External Frequency Sources DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 0.0~100.0% 0.0~100.0% 0.0~20.0mA 0.0~20.0mA 0.00~100.00% 0.00~100.00% 0.00~10.00 Sec 0.00~10.00 Sec 0.00~10.00 Sec...
  • Page 123 0.0 to 65500 Sec 0.0 to 65500 Sec 0.0 to 65500 Sec 0.0 to 65500 Sec 8-10 Factory Settings Setting 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 124 05-30 Time Duration Step 14 05-31 Time Duration Step 15 05-32 Time Unit Settings DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 0.0 to 65500 Sec 0.0 to 65500 Sec 0.0 to 65500 Sec 0.0 to 65500 Sec 00: 1 Sec 01: 0.1 Sec...
  • Page 125 01: Warn and coast to stop 02: Warn and keep operating 00: No fault 01: Oc (over-current) 02: Ov (over-voltage) 03: OH (over temperature) 04: OL (over load) 8-12 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Factory Customer Setting 390.0 780.0 10.0...
  • Page 126 Parameter Reset 06-16 Parameter Protection Password Input 06-17 Parameter Protection Password Setting DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 05: oL1 (over load 1) 06: EF (External Fault) (IGBT module is abnormal) 08: cF3 (driver’s internal circuitry is abnormal) 09: HPF (Hardware Protection...
  • Page 127 Calculate Total Running Time of the Motor (Day) Functions Display by model type Display by model type 30~120% 1~99% 0.0~3.0 0.0~10.0 0.0~10.0 00 to 1439 Min 00 to 65535 Day 8-14 Factory Settings Setting 100% 0.00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 128 08-19 Software Setting of the Brake Level (the action level of the brake resistor) 08-20 Vibration Compensation Factor 00~1000 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 00~100% 0.00~120.00 Hz 00: Disable 01: Trace from top downward 02: Trace from bottom upward 0.1~5.0 Sec...
  • Page 129 10: Start-up 11: JOG start-up 01: FWD command 10: REV command 11: Change direction command step accel/decel speed 01: 2 step accel/decel speed 10: 3 step accel/decel speed 11: 4 step accel/decel speed DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 130 Functions 09-06 Communication Operation Command 1 09-07 Communication Frequency Setting 09-08 Communication Operation Command 2 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings Bit8~11: 0000: Master speed 0001: 1 step speed 0010: 2 step speed 0011: 3 step speed 0100: 4...
  • Page 131 0.0: Disable 00: Warn and RAMP stop 01: Warn and COAST stop 02: Warn and keep operating 0: By PID controller 1: By AC drive 8-18 Factory Settings Setting 1000.0 1.00 0.00 600.0 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Customer...
  • Page 132 11-10 Treatment of Fixed Amount Circulation Malfunction 11-11 Stop Frequency of Auxiliary Motor DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Settings 00: Determined by group 01 01: 1.5 power curve 02: 1.7 power curve 03: 2 power curve 04: 3 power curve...
  • Page 133 VFD-F Series This page intentionally left blank. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 134: Specifications

    Multi-step selection 0 to 15, Jog, accel/decel inhibit, first to forth accel/decel switches, Multi-Function Input Signal Multi-Function Output AC Drive Operating, Frequency Attained, Desired Frequency Attained, Zero speed, Base Indication Analog Output Signal DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 230V Class 12.5 Proportional to Input Voltage 0.10-120.00Hz 4-10 15.5...
  • Page 135 DC Reactor: 25~215HP AC Reactor: 250~300HP 1~20HP Forced Fan-cooled C to 40 C Non-Condensing and not frozen C to 60 Below 90% RH (non-condensing) 9.80665m/s (1G) less than 20Hz, 5.88m/s DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED (0.6G) at 20 to 50Hz...

  • Page 136: B.1 All Brake Resistors & Brake Units Used In Ac Motor Drives

    13500W 5Ω 21600W 4Ω 73.5 21600W 4Ω 21600W 3.4Ω 27000W 2.5Ω 122.5 27000W 2.5Ω : Standard 4-pole motor DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Brake Unit Brake Model VFDB Resistors Model No. of Unit Used No. of Units Used BR080W200 BR300W100...
  • Page 137 -(N) to the neutral point of power system. ED% = T1/T0x100(%) Braking Time Cycle Time R/L1 U/T1 S/L2 V/T2 T/L3 W/T3 VFD Series brake MOTOR Thermal Overload Relay O.L. Brake Brake Resistor Unit Temperature Switch unit. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 138: B.1.1 Dimensions And Weights For Brake Resistors

    B.1.1 Dimensions and Weights for Brake Resistors (Dimensions are in millimeter) Order P/N: BR080W200, BR080W750, BR300W070, BR300W100, BR300W250, BR300W400, BR400W150, BR400W040 TYPE BR080W200 BR080W750 BR300W070 BR300W100 BR300W250 BR300W400 BR400W150 BR400W040 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED VFD-F Series MAX. WEIGHT(g)
  • Page 139 VFD-F Series Order P/N: BR500W030, BR500W100, BR1K0W020, BR1K0W075 TYPE BR500W030 BR500W100 BR1K0W020 BR1K0W075 Order P/N: BR1K0W050, BR1K2W008, BR1K2W6P8, BR1K5W005, BR1K5W040 MAX. WEIGHT(g) 1100 1100 2800 2800 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 140: B.1.2 Specifications For Brake Unit

    Heat Sink Overheat Alarm Output Power Charge Display Installation Location Operating Temperature -10 ℃ ～+50 ℃ Storage Temperature Humidity Vibration Wall-mounted Enclosed Type DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 230V Series 2015 2022 4030 660/690/720/760/800/830 ±3V 200~400VDC 400~800VDC Temperature over +95°C (203...

  • Page 141: B.1.3 Dimensions For Brake Unit

    VFD-F Series B.1.3 Dimensions for Brake Unit (Dimensions are in millimeter[inch]) Figure 1: VFDB2015, VFDB2022, VFDB4030, VFDB4045 121.0 [4.76] 130.0 [5.12] R3.3 [R0.13] 80.0 [3.15] CHARGE ACT. ERR. GREEN YELLOW DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 142 VFD-F Series Figure 2: VFDB4132 CHARGE ACT VFDB4132 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 143: B.2 Amd-Emi Filter Cross Reference

    3. Remove any paint on metal saddle for good ground contact with the plate and shielding. AC Drives Environment, restricted distribution) EMI Model Number 26TDT1W4C 50TDS4W4C 100TDS84C 150TDS84C 180TDS84C 200TDDS84C DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 144 VFD-F Series Remove any paint on metal saddle for good ground contact with the plate and shielding. saddle the plate with grounding Saddle on both ends Saddle on one end DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 145: B.3 Ac Reactor

    0.75 B-10 Inductance (mh) 3% impedance 5% impedance 0.15 0.11 0.09 0.075 0.06 0.05 DC Amps Inductance (mh) 25.00 11.50 11.50 6.00 3.75 4.00 2.68 2.00 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 0.85 0.45 0.23 0.185 0.15 0.125 0.105 0.085...
  • Page 146 AC Output Reactor Recommended Value 230V, 50/60Hz, 3-Phase Fundamental Amps 0.75 18.5 460V, 50/60Hz, 3-Phase Fundamental Amps 0.75 18.5 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Inductance (mH) Max. continuous Amps 3% impedance 1.25 37.5 52.5 82.5 0.25 0.15 0.075 Inductance (mH) Max.

  • Page 147: B.4 Non-Fuse Circuit Breaker Chart

    VFD022F43A/H VFD037F23A VFD037F43A/H VFD055F23A VFD055F43B/H VFD075F23A VFD075F43B/H VFD110F23A VFD110F43A/H VFD150F23A VFD150F43A/H VFD185F23A VFD185F43A/H VFD220F23A VFD220F43A/H VFD300F23A VFD300F43A/H VFD370F23A VFD370F43A/H VFD450F43A/H VFD550F43A/H VFD750F43A/H VFD900F43C/H VFD1100F43C/H VFD1320F43A/H VFD1600F43A/H VFD1850F43A/H VFD2200F43A/H 3-phase Recommended non-fuse breaker (A) B-12 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 148: B.5 Fuse Specification Chart

    VFD220F43A/H VFD300F23A VFD300F43A/H VFD370F23A VFD370F43A/H VFD450F43A/H VFD550F43A/H VFD750F43A/H VFD900F43C/H VFD1100F43C/H VFD1320F43A/H VFD1600F43A/H VFD1850F43A/H VFD2200F43A/H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED I (A) I (A) Input Output I (A) 15.5 20.6 11.2 B-13 VFD-F Series Line Fuse Bussmann P/N JJN-10 JJS-6...

  • Page 149: B.6.2 Explanation Of Display Message

    Display the driver's current status. MODE Change between different display mode. Right key Move the cursor to the right STOP/RESET Stops AC drive operation and reset the drive after fault occurred. RUN Key Start AC drive operation. DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

  • Page 150: B.6.3 Pu06 Operation Flow Chart

    Communication Error. Please check the AC motor drive user manual (Chapter 5, Group 9 Communication Parameter) for more details. B.6.3 PU06 Operation Flow Chart VFD-PU06 Operation Flow Chart Cannot write in DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED Descriptions keys. XX-XX XXXXX -ERR-...

  • Page 151: B.7 Relay Card

    6. Always use and operate this product within the limit of its specifications. 7. For other operation notes, please refer to the user’s manuals of AC motor drive. C to 40 C (non-condensing and not frozen) B-16 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 152 PCB-SUPPORT SCREW M3*P0.5 TORQUE=2~4Kgf-cm INSULATOR RELAY-CARD SCREW M3*P0.5 TORQUE=2~4Kgf-cm INSULATOR RELAY-CARD DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED PCB-SUPPORT CONTROL-BOARD PCB-SUPPORT PCB-SUPPORT CONTROL-BOARD B-17 VFD-F Series...

  • Page 153: B.8 Zero Phase Reactor

    Note 3: When long motor output cables are MOTOR used, an output zero phase reactor may be required to reduce radiated emissions from the cable. B-18 Zero Phase Reactor R/L1 U/T1 S/L2 V/T2 T/L3 W/T3 DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED MOTOR...
  • Page 154 Frame B Frame 150.0 135.0 [5.91] [5.32] NOTE Frame B(B1): VFD007F23A; VFD007F43A; VFD007F43H; VFD015F23A; VFD015F43A; VFD015F43H; VFD022F23A; VFD022F43A; VFD022F43H; VFD037F23A; VFD037F43A; VFD037F43H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 260.0 244.3 160.2 [10.24] [9.63] [6.31] VFD-F Series UNIT: mm [inch] [0.16] [0.32]...
  • Page 155 Frame C Frame 200.0 185.6 [7.88] [7.31] NOTE Frame C(C1): VFD055F23A; VFD055F43B; VFD055F43H; VFD075F23A; VFD075F43B; VFD075F43H; VFD110F23A; VFD110F43A; VFD110F43H; VFD150F43A; VFD150F43H 323.0 303.0 183.2 [12.72] [11.96] [7.22] UNIT: mm [inch] 76.5 [3.01] [0.12] [0.28] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED [0.28]...
  • Page 156 Frame D Frame 250.0 226.0 [9.84] [8.90] NOTE Frame D(D1): VFD150F23A; VFD185F23A; VFD185F43A; VFD185F43H; VFD220F23A; VFD220F43A; VFD220F43H; VFD300F43A; VFD300F43H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 403.8 384.0 205.4 [15.90] [15.12] [8.08] VFD-F Series UNIT: mm [inch] 110.0 10.0 [4.33] [0.31]...
  • Page 157 560.0 260.0 [23.19] [22.05] [10.24] 589.0 560.0 260.0 [23.19] [22.05] [10.24] UNIT: mm [inch] 132.5 18.0 13.0 13.0 [5.22] [0.71] [0.51] [0.51] 132.5 18.0 13.0 13.0 [5.22] [0.71] [0.51] [0.51] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 18.0 [0.71] 18.0 [0.71]...
  • Page 158 Frame G Frame 425.0 381.0 850.0 819.5 [16.73] [15.00] [33.46] [32.26] NOTE Frame G(G1): VFD1100F43C; VFD1100F43H; VFD1320F43A; VFD1320F43H; VFD1600F43A; VFD1600F43H DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED VFD-PU01 RUN STOP MODE PROG DATA STOP RESET 746.0 264.0 19.0 18.0 [30.08] [10.39] [0.75]...
  • Page 159 NOTE Frame H(H1): VFD1850F43A; VFD1850F43H; VFD2200F43A; VFD2200F43H VFD-PU01 RUN STOP MODE PROG DATA STOP RESET 1150.0 1119.0 1072.6 [45.28] [44.06] [42.23] UNIT: mm [inch] 360.0 20.00 13.0 13.0 [14.17] [0.79] [0.51] [0.51] DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED 20.00 [0.79]...
  • Page 160 VFD-F Series VFD-PU01 Unit: mm (inches) 19.0 [0.75] 73.0 [2.87] 44.0 [1.73] M4* 0.7(2X) MODE PROG DATA STOP DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...
  • Page 161 VFD-F Series KPF-CC01 Unit: mm (inches) DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED...

This manual is also suitable for:

Vfd007f23aVfd007f43aVfd007f43hVfd015f23aVfd015f43aVfd015f43h ... Show all

Table of Contents
