KA01142D/06/EN/02.13
71233366
Products
Brief Operating Instructions
Proline Promag H 100
Electromagnetic flowmeter
These Instructions are Brief Operating Instructions; they do not
replace the Operating Instructions included in the scope of
supply.
For detailed information, refer to the Operating Instructions
and other documentation on the CD-ROM provided or visit
"www.endress.com/deviceviewer".
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proline Promag H 100

Summary of Contents for Endress+Hauser Proline Promag H 100

  • Page 1 Solutions Services KA01142D/06/EN/02.13 71233366 Brief Operating Instructions Proline Promag H 100 Electromagnetic flowmeter These Instructions are Brief Operating Instructions; they do not replace the Operating Instructions included in the scope of supply. For detailed information, refer to the Operating Instructions and other documentation on the CD-ROM provided or visit "www.endress.com/deviceviewer".

  • Page 2: Table Of Contents

    Table of contents Proline Promag H 100 Table of contents Document information ............3 Symbols used .

  • Page 3: Document Information

    Proline Promag H 100 Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. A0011189-EN WARNING! WARNING This symbol alerts you to a dangerous situation.
  • Page 4 Document information Proline Promag H 100 1.1.3 Tool symbols Symbol Meaning Allen key A0011221 Open-ended wrench A0011222 1.1.4 Symbols for certain types of information Symbol Meaning Allowed Indicates procedures, processes or actions that are allowed. A0011182 Preferred Indicates procedures, processes or actions that are preferred.

  • Page 5: Basic Safety Instructions

    Proline Promag H 100 Basic safety instructions Symbol Meaning Flow direction A0013441 Hazardous area Indicates a hazardous area. A0011187 Safe area (non-hazardous area) Indicates a non-hazardous area. A0011188 Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣...

  • Page 6: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 7: Security

    Proline Promag H 100 Basic safety instructions It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions.

  • Page 8: Product Description

    Product description Proline Promag H 100 Product description Product design 3.1.1 Device version with HART, Modbus RS485 and PROFIBUS DP communication types A0017609  1 Important components of a measuring device Transmitter housing cover Main electronics module Transmitter housing Sensor...
  • Page 9 Proline Promag H 100 Product description 3.1.2 Device version with EtherNet/IP communication type A0017257  2 Important components of a measuring device Transmitter housing cover I/O electronics module for EtherNet/IP Main electronics module Transmitter housing Sensor Endress+Hauser...

  • Page 10: Incoming Acceptance And Product Identification

    Incoming acceptance and product identification Proline Promag H 100 Incoming acceptance and product identification Incoming acceptance A0015502 A0013843 A0013695 A0015502 A0013698 A0015502 A0013699 Endress+Hauser...

  • Page 11: Product Identification

    Proline Promag H 100 Incoming acceptance and product identification A0015502 A0013697 If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. Product identification The following options are available for identification of the measuring device: • Nameplate specifications •...

  • Page 12: Storage And Transport

    Storage and transport Proline Promag H 100 Storage and transport Storage conditions Observe the following notes for storage: • Store in original packaging. • Do not remove protective covers or protective caps installed on process connections. • Protect from direct sunlight.
  • Page 13 Proline Promag H 100 Storage and transport A0015604 A0015605 Endress+Hauser...

  • Page 14: Installation

    Installation Proline Promag H 100 Installation Installation conditions No special measures such as supports are necessary. External forces are absorbed by the construction of the device. 6.1.1 Mounting position Mounting location h ≥ 2 × DN A0017061 Installation in down pipes Install a siphon or a vent valve downstream of the sensor in down pipes whose length h ≥...
  • Page 15 Proline Promag H 100 Installation Installation in partially filled pipes A partially filled pipe with a gradient necessitates a drain-type configuration. The empty pipe detection (EPD) function offers additional protection by detecting empty or partially filled pipes. • Do not install the sensor at the lowest point in the drain: risk of solids accumulating.
  • Page 16 Installation Proline Promag H 100 A0019602  5 Horizontal orientation EPD electrode for empty pipe detection Measuring electrodes for signal detection Inlet and outlet runs 5 × DN ³ 2 × DN ³ A0016275 For the dimensions and installation lengths of the device, see the "Technical Information"...
  • Page 17 Proline Promag H 100 Installation If operating outdoors: • Install the measuring device in a shady location. • Avoid direct sunlight, particularly in warm climatic regions. • Avoid direct exposure to weather conditions. Temperature tables SI units [°C] [85 °C] [100 °C]...
  • Page 18 Installation Proline Promag H 100 Vibrations A0016266  6 Measures to prevent vibration of the device > 10 m (33 ft) Adapters [mbar] 8 m/s 7 m/s 6 m/s 5 m/s 4 m/s max. 8° 3 m/s 2 m/s 1 m/s...

  • Page 19: Mounting The Measuring Device

    Proline Promag H 100 Installation Mounting the measuring device 6.2.1 Required tools For sensor For flanges and other process connections: • Screws, nuts, seals etc. are not included in the scope of supply and must be provided by the customer.
  • Page 20 In particular, it is absolutely essential to secure the sensor additionally if plastic process connections are used. An appropriate wall mounting kit can be ordered separately as an accessory from Endress+Hauser . DN 2…25 DN 40…150 (1/12…1 ) "...
  • Page 21 • Grounding rings can be ordered separately as an accessory from Endress+Hauser . When ordering make sure that the grounding rings are compatible with the material...
  • Page 22 Installation Proline Promag H 100 A0002651  8 Installing grounding rings Hexagonal-headed bolts of process connection O-ring seals Grounding ring or plastic disk (spacer) Sensor Release the 4 or 6 hexagonal-headed bolts (1) and remove the process connection from the sensor (4).

  • Page 23: Post-Installation Check

    Proline Promag H 100 Installation Post-installation check Is the device undamaged (visual inspection)?  Does the measuring device conform to the measuring point specifications? For example: • Process temperature  • Process pressure (refer to the section on "Pressure-temperature ratings" in the "Technical Information"...

  • Page 24: Electrical Connection

    Electrical connection Proline Promag H 100 Electrical connection The measuring device does not have an internal circuit breaker. For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
  • Page 25 Proline Promag H 100 Electrical connection Cable type Twisted pairs Loop resistance ≤110 Ω/km Signal damping Max. 9 dB over the entire length of the cable cross-section Shielding Copper braided shielding or braided shielding with foil shield. When grounding the cable shield, observe the grounding concept of the plant.
  • Page 26 Electrical connection Proline Promag H 100 7.1.3 Terminal assignment 7.1.4 Pin assignment, device plug Supply voltage Supply voltage for all communication types (on the device side) Assignment Coding Plug/socket DC24 V Plug DC24 V Grounding/shielding A0016809 4-20 mA HART with pulse/frequency/switch output...
  • Page 27 Proline Promag H 100 Electrical connection Modbus RS485, non-hazardous area and Zone 2/Div. 2 (on the device side) Assignment Coding Plug/socket Socket Modbus RS485 Modbus RS485 Grounding/shielding A0016811 EtherNet/IP EtherNet/IP (on the device side) Assignment Coding Plug/socket Socket A0016812 7.1.5...

  • Page 28: Connecting The Measuring Device

    Electrical connection Proline Promag H 100 7.1.6 Preparing the measuring device Remove dummy plug if present. NOTICE! Insufficient sealing of the housing! Operational reliability of the measuring device could be compromised. Use suitable cable glands corresponding to the degree of protection.
  • Page 29 Proline Promag H 100 Electrical connection 8 mm 8 mm 3 mm 10 (0.4) mm (in) A0017844  10 Device versions with connection examples Cable Device plug for signal transmission Device plug for supply voltage ‣ Connect the cable in accordance with the terminal assignment or the device plug pin assignment (→...
  • Page 30 • Ground rings can be ordered separately from Endress+Hauser as accessories. When placing the order, make certain that the ground rings are compatible with the material used for the electrodes.
  • Page 31 Proline Promag H 100 Electrical connection Potential equalization via additional ground ring A0002651 Allen screw (process connection) O-ring seals Plastic washer (spacer) or ground ring Sensor Endress+Hauser...

  • Page 32: Hardware Settings

    Electrical connection Proline Promag H 100 Potential equalization via ground electrodes on process connection A0017293 Allen screw (process connection) Integrated ground electrodes O-ring seal Sensor Hardware settings 7.3.1 Setting the device address EtherNet/IP The IP address of the measuring device can be configured for the network via DIP switches.
  • Page 33 Proline Promag H 100 Electrical connection IP address range 1 to 254 (4th octet) IP address broadcast Addressing mode ex works Software addressing; all DIP switches for hardware addressing are set to OFF. IP address ex works DHCP server active For device addressing via software (→...
  • Page 34 Electrical connection Proline Promag H 100 Setting the address OFF ON - Software addressing - Write protection - Not used A0021265  11 Addressing using DIP switches on the I/O electronics module Disable software addressing via DIP switch 8 (OFF).
  • Page 35 Proline Promag H 100 Electrical connection 390 Ω DIP 1 OFF ON Bus polarisation DIP 2 220 Ω Bus termination Bus polarisation Not used DIP 3 390 Ω A0021274  12 Termination using DIP switches on the I/O electronics module (for baud rates < 1.5 MBaud)

  • Page 36: Ensuring The Degree Of Protection

    Electrical connection Proline Promag H 100 If the transmitter is used in the non-hazardous area or Zone 2/Div. 2 4 - Bus termination 3 - Not used 220 W 2 - Not used 1 - Write protection A0017610  13...

  • Page 37: Post-Connection Check

    Proline Promag H 100 Electrical connection Insert dummy plugs into unused cable entries. Post-connection check Are cables or the device undamaged (visual inspection)?  Do the cables comply with the requirements (→  24)?  Do the cables have adequate strain relief? ...

  • Page 38: Operation Options

    Operation options Proline Promag H 100 Operation options Structure and function of the operating menu 8.1.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation Setup Diagnostics Operating menu for experts Expert A0014058-EN 8.1.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles.
  • Page 39 Proline Promag H 100 Operation options 8.2.2 Prerequisites Hardware Connecting cable Standard Ethernet cable with RJ45 connector Computer RJ45 interface Measuring device Web server must be enabled; factory setting: ON Software of the computer Web browsers supported • Microsoft Internet Explorer 7.x, 8.x, 9.x •...
  • Page 40 Operation options Proline Promag H 100 Device tag Webserv.language English Ent. access code Access stat.tool Maintenance A0017362 Device tag (→  46) Picture of device 8.2.4 Logging on Access code 0000 (factory setting); can be changed by customer (→  47) 8.2.5...

  • Page 41: Access To The Operating Menu Via The Operating Tool

    Proline Promag H 100 Operation options Header The following information appears in the header: • Device tag (→  46) • Device status with status signal • Current measured values Function row Functions Meaning Measured values The measured values of the device are displayed...
  • Page 42 Operation options Proline Promag H 100 A0016925 Service interface (CDI) of the measuring device Commubox FXA291 Computer with "FieldCare" operating tool with COM DTM "CDI Communication FXA291" 8.3.2 Via service interface (CDI-RJ45) A0016926  14 Connection for the order code for "Output", option B: 4-20 mA HART, pulse/frequency/switch...
  • Page 43 Proline Promag H 100 Operation options A0021270  15 Connection for order code for "Output", option L: PROFIBUS DP Service interface (CDI -RJ45) of the measuring device with access to the integrated Web server Computer with Web browser (e.g. Internet Explorer) for accessing the integrated device Web server or with "FieldCare"...
  • Page 44 Operation options Proline Promag H 100 8.3.3 Via Ethernet network This communication interface is present in the following device version: Order code for "Output", option N: EtherNet/IP A0016961 Ethernet network Automation system, e.g. "RSLogix" (Rockwell Automation) Workstation for measuring device operation: with Add-on Profile Level 3 for "RSLogix 5000" (Rockwell Automation) or with Electronic Data Sheet (EDS) Computer with Web browser (e.g.

  • Page 45: System Integration

    Proline Promag H 100 System integration the I/O electronics module to ON, restart the device and enter the default setting for the IP address 192.168.1.212. Establish the online connection to the device. For device version with Modbus RS485 communication type Via service interface (CDI) and "FieldCare"...

  • Page 46: Establishing A Connection Via Fieldcare

    Commissioning Proline Promag H 100 10.2 Establishing a connection via FieldCare • For FieldCare connection (→  41) • For establishing a connection via FieldCare (→  44) 10.3 Configuring the device address via software Applies only to device version with EtherNet/IP communication type Software addressing is carried out in the Communication submenu.

  • Page 47: Protecting Settings From Unauthorized Access

    Proline Promag H 100 Commissioning Navigation "Setup" menu → Device tag Parameter overview with brief description Parameters Description User entry Factory setting Device tag Enter tag for measuring Max. 32 characters, such as Promag point. letters, numbers or special characters (e.g. @, %, /).
  • Page 48 Commissioning Proline Promag H 100 10.6.2 Write protection via write protection switch The write protection switch makes it possible to block write access to the entire operating menu with the exception of the following parameters: • External pressure • External temperature •...
  • Page 49 Proline Promag H 100 Commissioning OFF ON - Write protection - Default Ethernet network settings IP 192.168.1.212 A0017915 For device version with PROFIBUS DP communication type OFF ON - Software addressing - Write protection - Not used A0021262 ‣ Setting the write protection switch on the electronics module to the ON position enables the hardware write protection.

  • Page 50: Diagnostic Information

    Diagnostic information Proline Promag H 100 Diagnostic information Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established and on the home page of the web browser once the user has logged on.
