- Page 1 Operating Instructions Proline Promass 80 Coriolis Mass Flow Measuring System BA00057D/06/EN/13.12 71197479 Valid as of version V 3.01.XX (device software)
-
Page 3: Table Of Contents
5.2.1 General notes ..... . 33 5.2.2 Enabling the programming mode ..33 5.2.3 Disabling the programming mode ..33 Endress+Hauser... - Page 4 10.1.15 Documentation ....109 Index ......110 Endress+Hauser...
-
Page 5: Safety Instructions
Strict compliance with the instructions in the Operating Instructions is mandatory. • Endress+Hauser is willing to assist in clarifying the chemical resistance properties of parts wetted by special fluids, including fluids used for cleaning. However, small changes in temperature, concentration or the degree of contamination in the process can result in changes of the chemical resistance properties. -
Page 6: Operational Safety
• For measuring systems used in SIL 2 applications, the separate manual on functional safety must be observed. • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser distributor will supply you with current information and updates to these Operating Instructions. Return •... -
Page 7: Identification
• Promass F, Promass E, Promass A, Promass H, Promass I, Promass S or Promass P sensor. Two versions are available: • Compact version: transmitter and sensor form a single mechanical unit. • Remote version: transmitter and sensor are installed separately. Endress+Hauser... -
Page 8: Nameplate Of The Transmitter
Additional function and software Available inputs / outputs Reserved for information on special products Please refer to operating instructions / documentation Reserved for certificates, approvals and for additional information on device version Patents Degree of protection Ambient temperature range Endress+Hauser... -
Page 9: Nameplate Of The Sensor
Accuracy of density measurement (Density cal.) Additional information Reserved for information on special products Ambient temperature range Degree of protection Please refer to operating instructions / documentation Reserved for additional information on device version (approvals, certificates) Patents Flow direction Endress+Hauser... -
Page 10: Nameplate For Connections
Version of device software currently installed (Device SW) Installed communication type (Communication) Information on current communication software (Drivers: Device Revision and Device Description), Date of installation (Date) Current updates to data specified in points 8 to 11 (Update1, Update 2) Endress+Hauser... -
Page 11: Certificates And Approvals
Laboratory Procedures" and with the EMC requirements of IEC/EN 61326. The measuring system described in these Operating Instructions thus complies with the statutory requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. -
Page 12: Installation
The center of gravity of the assembled measuring device might be higher than the points around which the slings are slung. At all times, therefore, make sure that the device does not unexpectedly turn around its axis or slip. a0004294 Fig. 4: Instructions for transporting sensors with > DN 40 (1 ½") Endress+Hauser... -
Page 13: Storage
Accumulated air or gas bubbles in the measuring tube can result in an increase in measuring errors. Avoid the following mounting locations in the pipe installation: • Highest point of a pipeline. Risk of air accumulating. • Directly upstream of a free pipe outlet in a vertical pipeline. a0003605 Fig. 5: Mounting location Endress+Hauser... - Page 14 Such effects can be prevented when system pressure is sufficiently high. Therefore, the following locations should be preferred for installation: • Downstream from pumps (no danger of vacuum) • At the lowest point in a vertical pipe Endress+Hauser...
-
Page 15: Orientation
• Mounted directly on a wall using the base plate • Measuring device supported on an angle bracket mounted on the wall 10 mm A0018980 Horizontal We recommend the following installation version when mounting horizontally: • Measuring device standing on a firm support base A0018979 Endress+Hauser... - Page 16 • For fluids with very high temperatures we recommend the horizontal orientation with the transmitter head pointing downwards (Fig. H2) or the vertical orientation (Fig. V). • For fluids with very low temperatures, we recommend the horizontal orientation with the transmitter head pointing upwards (Fig. H1) or the vertical orientation (Fig. V). Endress+Hauser...
-
Page 17: Special Installation Instructions
The arrow indicates the direction of flow (direction of fluid flow through the pipe). The label shows the installation orientation for horizontal drainability. The underside of the process connection is indicated by a scribed line. This line indicates the lowest point of the eccentric process connection. Endress+Hauser... - Page 18 It is not necessary to support the sensor under any circumstances for operational performance. If the requirement exists to support the sensor the following recommendation should be followed. A0007397 Fig. 10: Promass P, mounted with mounting clamp 1019 36.5 44.1 Endress+Hauser...
-
Page 19: Heating
(e.g. V330-35A) with the following properties: – Relative magnetic permeability μ – Plate thickness d 0.35 mm (0.014") • Information on permissible temperature ranges ä 94 Special heating jackets which can be ordered as accessories from Endress+Hauser are available for the sensors. Endress+Hauser... -
Page 20: Thermal Insulation
Consequently, the sensors require no special measures for attachment. 3.2.9 Limiting flow Relevant information can be found in the "Technical Data" section under Measuring range ä 71 or Limiting Flow ä 95. Endress+Hauser... -
Page 21: Installation
Carefully lift the transmitter housing as far as it will go. Turn the transmitter housing to the desired position (max. 2 × 90° in either direction). Lower the housing into position. Retighten the two securing screws. a0004303 Fig. 14: Turning the transmitter housing (stainless steel field housing) Endress+Hauser... -
Page 22: Installing The Wall-Mount Housing
– Screw head: max. Ø 10.5 mm (0.41") Secure the transmitter housing to the wall as indicated. Screw the cover of the connection compartment (a) firmly onto the housing. 35 (1.38) 90 (3.54) 192 (7.56) mm (inch) a0001130 Fig. 15: Mounted directly on the wall Endress+Hauser... - Page 23 If a warm pipe is used for installation, make sure that the housing temperature does not exceed the max. permitted value of +60 °C (+140 °F). Ø 20…70 (Ø 0.79…2.75) 155 ( ~ 6.1) mm (inch) a0001132 Fig. 17: Pipe mounting (wall-mount housing) Endress+Hauser...
-
Page 24: Turning The Local Display
Has the correct orientation been chosen for the sensor, in other words is it suitable for sensor type, fluid properties (outgassing, with entrained solids) and fluid temperature? Process environment / process conditions Notes Is the measuring device protected against moisture and direct sunlight? Endress+Hauser... -
Page 25: Wiring
Wiring Warning! When connecting Ex-certified devices, see the notes and diagrams in the Ex-specific supplement to these Operating Instructions. Please do not hesitate to contact your Endress+Hauser sales office if you have any questions. Hinweis! The device does not have an internal power switch. For this reason, assign the device a switch or power-circuit breaker which can be used to disconnect the power supply line from the power grid. -
Page 26: Cable Specification, Connecting Cable
– Wiring diagram (aluminum housing) å 20 Perform wiring: – Wiring diagram (stainless steel housing å 21 – Wiring diagram (wall-mount housing) å 22 – Terminal assignment ä 28 Screw the cover of the connection compartment (f) back onto the transmitter housing. Endress+Hauser... - Page 27 Signal cable: Terminals Nos. 20–27 ä 28 Terminal No. 2: N for AC, L- for DC Ground terminal for protective ground Ground terminal for signal cable shield Service adapter for connecting service interface FXA193 (Fieldcheck, FieldCare) Cover of the connection compartment Endress+Hauser...
-
Page 28: Terminal Assignment
Frequency output HART Frequency output Current output Ex i 80***-***********S Ex i, passive active, HART Frequency output Current output Ex i 80***-***********T Ex i, passive passive, HART Current output 1 80***-***********8 Status input Frequency output Current output 2 HART Endress+Hauser... -
Page 29: Hart Connection
In order to connect a PC with operating software (e.g. FieldCare), a HART modem (e.g. Commubox FXA195) is needed. ³ –27 a0004592 Fig. 24: Electrical connection of a PC with operating software PC with operating software Auxiliary energy Shielding Other switching units or PLC with passive input HART modem, e.g. Commubox FXA195 Endress+Hauser... -
Page 30: Degree Of Protection
" Caution! Do not loosen the screws of the sensor housing, as otherwise the degree of protection guaranteed by Endress+Hauser no longer applies. Post connection check Perform the following checks after completing electrical installation of the measuring device: Device condition and specifications... -
Page 31: Operation
– Press and hold down +/– keys for longer than 3 seconds Return directly to HOME position – Cancel data entry – HOME position Entry into the function matrix Enter key – Save the numerical values you input or settings you change Endress+Hauser... -
Page 32: Brief Operating Instructions To The Function Matrix
– Press and hold down Esc key ( X ) for longer than 3 seconds HOME position Exit the function matrix: – Repeatedly press Esc key ( X ) Return step-by-step to HOME position > 3 s – – – – a0001142 Fig. 27: Selecting functions and configuring parameters (function matrix) Endress+Hauser... -
Page 33: General Notes
• If programming is disabled and the P operating elements are pressed in any function, a prompt for the code automatically appears on the display. • If "0" is entered as the customer's code, programming is always enabled! • The Endress+Hauser service organization can be of assistance if you mislay your personal code. " Caution! Changing certain parameters such as all sensor characteristics, for example, influences numerous functions of the entire measuring system, particularly measuring accuracy. -
Page 34: Error Messages
The response of the outputs (failsafe mode) can be defined by means of functions in the • Displayed as Lightning flash ( $ ), error type (S: system error, P: process error) Note! For security reasons, error messages should be output via the status output. Endress+Hauser... -
Page 35: Communication
Operating program "FieldCare" FieldCare is Endress+Hauser’s FDT-based plant asset management tool and allows the configuration and diagnosis of intelligent field devices. By using status information, you also have a simple but effective tool for monitoring devices. The Proline flowmeters are accessed via a HART interface FXA195 or via the service interface FXA193. -
Page 36: Current Device Description Files
Field Xpert handheld terminal • Use update function of handheld terminal • www.endress.com Download-Area FieldCare / DTM • CD–ROM (Endress+Hauser order number 56004088) • DVD (Endress+Hauser order number 70100690) • www.endress.com Download-Area • www.endress.com Download-Area SIMATIC PDM... -
Page 37: Hart Commands
• Third process variable = Density • Fourth process variable = Temperature Note! • You can set the assignment of device variables to process variables using Command 51. • Manufacturer-specific units are represented using the HART unit code "240". Endress+Hauser... - Page 38 – Byte 16: OEM dealer ID, 17 = E+H Factory setting: Primary process variable = Mass flow Note! • You can set the assignment of device variables to process variables using Command 51. • Manufacturer-specific units are represented using the HART unit code "240". Endress+Hauser...
- Page 39 An entry value of 0 exits the simulation mode: Byte 0-3: Output current in mA Factory setting: Primary process variable = Mass flow Note! You can set the assignment of device variables to process variables with Command 51. Perform master reset none none Access = write Endress+Hauser...
- Page 40 See data ä 36 Code of the supported device variables: Factory setting: • Primary process variable = Mass flow • Secondary process variable = Totalizer 1 • Third process variable = Density • Fourth process variable = Temperature Endress+Hauser...
- Page 41 This parameter sets the number of preambles which are As a response, the current number of the preambles is response message inserted in the response messages: displayed in the response message: Access = write Byte 0: Number of preambles (2 to 20) Byte 0: Number of preambles Endress+Hauser...
-
Page 42: Device Status / Error Messages
One of the measuring tube sensor coils (inlet or outlet) is likely defective. 10-1 10-2 Amplifier error 10-3 12-1 Maximum flow value entered is exceeded. 12-7 New amplifier software version is loaded. Currently no other commands are possible. 13-0 Upload and download of device files. Currently no other commands are possible. Endress+Hauser... - Page 43 Overdriving of the internal analog to digital converter. A continuation of the measurement is still possible! 19-4 19-5 The electronics' measuring range will be exceeded. The mass flow is too high. 20-5 The zero point adjustment is not possible or has been canceled. Endress+Hauser...
-
Page 44: Commissioning
SYSTEM OK Beginning of normal measuring mode Normal measuring mode commences as soon as startup completes. Various measured value and/or status variables appear on the display (HOME position).g Note! If startup fails, an error message indicating the cause is displayed. Endress+Hauser... -
Page 45: Quick Setup
20 mA 20 mA Time constant Time constant Output signal Failsafe mode Failsafe mode Failsafe mode Time constant Failsafe mode Configuration another output ? Automatically configuration display ? Automatically parameterization of the display a0004645-en Fig. 29: "Commissioning" Quick Setup Endress+Hauser... - Page 46 The "automatic parameterization of the display" option contains the following basic settings/factory settings: YES: line 1= mass flow; line 2 = totalizer 1; information line = operating/system conditions NO: The existing (selected) settings remain. Endress+Hauser...
-
Page 47: Configuration
Incorrectly set jumpers can cause overcurrents that would destroy either the measuring device or external devices connected to it. Installation of the I/O board is the reverse of the removal procedure. a0001044 Fig. 30: Configuring the current output (I/O board) Active current output (default) Passive current output Endress+Hauser... -
Page 48: Two Current Outputs: Active/Passive
Installation of the I/O board is the reverse of the removal procedure. a0001214 Fig. 31: Configuring current outputs with the aid of jumpers (I/O board) Current output 1 with HART Active current output (default) Passive current output Current output 2 (optional, plug-in module) Active current output (default) Passive current output Endress+Hauser... -
Page 49: Adjust
In instances of this nature, please contact your Endress+Hauser service center. • You can view the currently valid zero point value using the ZERO POINT function (see the "Description of Device Functions"... - Page 50 ZERO ADJUST NOT POSSIBLE. When the zero point adjustment completes, the ZERO ADJUST. function ZERO ADJUST. reappears on the display. CANCEL After actuating the Enter key, the new zero point value is displayed. ZERO POINT Simultaneously pressing P HOME position Endress+Hauser...
-
Page 51: Density Adjustment
" Caution! If a density adjustment does not complete correctly, you can select the RESTORE ORIGINAL function to reactivate the default density coefficient. Use Q Use Q to return to the HOME position (press P simultaneously). Endress+Hauser... -
Page 52: Rupture Disk
• Use only low gauge pressure to purge. Maximum pressure 5 bar. Data storage device (HistoROM) At Endress+Hauser, the term HistoROM refers to various types of data storage modules on which process and measuring device data are stored. By plugging and unplugging such modules, device configurations can be duplicated onto other measuring devices to cite just one example. -
Page 53: Maintenance
Replacement is necessary only in special circumstances, for example if aggressive or corrosive fluids are incompatible with the seal material. Note! • The period between changes depends on the fluid properties and on the frequency of cleaning cycles in the case of CIP/SIP cleaning. • Replacement seals (accessories) Endress+Hauser... -
Page 54: Accessories
Accessories Proline Promass 80 Accessories Various accessories, which can be ordered separately from Endress+Hauser, are available for the transmitter and the sensor. The Endress+Hauser service organization can provide detailed information on the order code of your choice. Device-specific accessories Accessory... -
Page 55: Communication-Specific Accessories
Power is supplied to the Commubox via the USB port. Service-specific accessories Accessory Description Order code Applicator Software for selecting and configuring Endress+Hauser DXA80 – * flowmeters: • Calculating all necessary data to determine the optimal flowmeter: e.g. nominal diameter, pressure drop, performance characteristics or process connections •... -
Page 56: Troubleshooting
– 03:00:05 = duration of error occurrence (in hours, minutes and seconds) – #702 = error number " See the information ä 34 Caution! ▼ Other error (without error message) Diagnosis and rectification ä 61 Some other error has occurred. Endress+Hauser... -
Page 57: System Error Messages
Caution! In the event of a serious fault, a flowmeter might have to be returned to the manufacturer Endress+Hauser ä 69. for repair. Important procedures must be carried out before you return a flowmeter to Always enclose a duly completed "Declaration of contamination" form. - Page 58 2 . 10 Hz a0004437 3. Reduce flow. S: FREQ. LIM The measuring tube oscillation frequency is outside the Contact your Endress+Hauser service organization. $ : # 379 to 380 permitted range. Causes: – Measuring tube damaged – Sensor defective or damaged S: FLUIDTEMP.MIN.
- Page 59 Switch off simulation. !: # 671 to 674 S: SIM. FAILSAFE Simulation of response to error (outputs) active. Switch off simulation. !: # 691 S: SIM. MEASURAND Simulation of measuring variables (e.g. mass flow). Switch off simulation. !: # 692 Endress+Hauser...
-
Page 60: Process Error Messages
(v = 0 m/s) ä 49. P: ABJ. ZERO FAIL The zero point adjustment is not possible or has been Make sure that zero point adjustment is carried out at "zero flow" !: # 731 canceled. Endress+Hauser... -
Page 61: Process Errors Without Messages
Returning devices to Endress+Hauser ä 69. The procedures on must be carried out before you return a flowmeter requiring repair or calibration to Endress+Hauser Always enclose a duly completed "Declaration of contamination" form with the flowmeter. You will find a preprinted "Dangerous Goods Sheet"... -
Page 62: Response Of Outputs To Errors
HOLD VALUE The totalizers continue to count the flow in accordance with the last valid flow value (before the error occurred). Status output nonconductive in the event of fault or power supply failure Status output No effect on status output Endress+Hauser... -
Page 63: Spare Parts
The illustration below shows the available scope of spare parts. Note! serial number printed on the transmitter's nameplate ä 7. You can order spare parts directly from your Endress+Hauser service organization by providing the Spare parts are shipped as sets comprising the following parts: • Spare part •... -
Page 64: Removing And Installing Printed
" Caution! Use only original Endress+Hauser parts. å 34, installation and removal: Unscrew cover of the electronics compartment from the transmitter housing. Remove the local display (1) as follows: –... - Page 65 Local display Latch Ribbon cable (display module) Screws of electronics compartment cover Aperture for installing/removing boards Power unit board Amplifier board Signal cable (sensor) Excitation current cable (sensor) S-DAT (sensor data memory) I/O board (flexible assignment) I/O board (permanent assignment) Endress+Hauser...
- Page 66 " Caution! Use only original Endress+Hauser parts. å 35, installation and removal: Loosen the screws and open the hinged cover (1) of the housing. Loosen the screws securing the electronics module (2). Then push up electronics module and pull it as far as possible out of the wall-mount housing.
- Page 67 Electronics module Ribbon cable (display module) Screws of electronics compartment cover Aperture for installing/removing boards Power unit board Amplifier board Signal cable (sensor) Excitation current cable (sensor) S-DAT (sensor data memory) I/O board (flexible assignment) I/O board (permanent assignment) Endress+Hauser...
-
Page 68: Replacing The Device Fuse
– Power supply 85 to 260 V AC 0.8 A slow-blow / 250 V; 5.2 × 20 mm – Ex-rated devices see the Ex documentation Installation is the reverse of the removal procedure. " Caution! Use only original Endress+Hauser parts. a0001148 Fig. 36: Replacing the device fuse on the power unit board Protective cap... -
Page 69: Return
Costs incurred for waste disposal and injury (burns, etc.) due to inadequate cleaning will be charged to the owner-operator. The following steps must be taken before returning a flow measuring device to Endress+Hauser, e.g. for repair or calibration: • Always enclose a duly completed "Declaration of contamination" form. Only then can Endress+Hauser transport, examine and repair a returned device. - Page 70 – HART operating via Universal Commands and Common Practice Commands 05.2001 Amplifier: Software adjustment 1.01.01 03.2001 Amplifier: 1.01.00 11.2000 Amplifier: Original software 50098468/11.00 1.00.xx Compatible with: Communication module: – Fieldtool 1.01.xx – HART Communicator DXR 275 (OS 4.6 or higher) with Rev. 1, DD 1. Endress+Hauser...
-
Page 71: Technical Data
0 to 18000 kg/h 0 to 660 lb/min 1 ½" 0 to 45000 kg/h 0 to 1650 lb/min 2" 0 to 70000 kg/h 0 to 2570 lb/min 3"* 0 to 180000 kg/h 0 to 6600 lb/min * only Promass E Endress+Hauser... - Page 72 = Gas density in [kg/m (lb/ft )] for process conditions Here, g can never be greater than g max(G) max(F) Measuring ranges for gases (Promass F): [mm] [inch] 3/8" ½" 1" 1 ½" 2" 3" 4" 6" 10" Endress+Hauser...
- Page 73 Measuring ranges for gases (Promass I) [mm] [inch] 3/8" 1/2" 15 FB 1/2" FB 1" 25 FB 1" FB 1 ½" 40 FB 1 ½" FB 2" 50 FB 2" FB 3" FB = Full bore versions of Promass I Endress+Hauser...
-
Page 74: Output
"Nonconductive" in the event of fault or power supply failure Load See "Output signal" Switching output Status output: Open collector, max. 30 V DC / 250 mA, galvanically isolated. Configurable for: error messages, Empty Pipe Detection (EPD), flow direction, limit values. Endress+Hauser... -
Page 75: Power Supply
Lasting min. 1 power cycle: • EEPROM saves measuring system data if power supply fails. • S-DAT is an exchangeable data storage chip with sensor specific data: (nominal diameter, serial number, calibration factor, zero point etc.). Potential equalization No measures necessary. Endress+Hauser... -
Page 76: Performance Characteristics
[lb/min] 1/24" 0.73 0.0010 0.000036 1/12" 3.70 0.0050 0.00018 1/8" 16.5 0.0225 0.0008 Example for max. measured error ±0.5 ±0.4 ±0.3 ±0.2 ±0.1 100 kg/h A0013422 Fig. 37: Max. measured error in % o.r. (example: Promass A, DN 2) Endress+Hauser... - Page 77 – Max. measured error: ± (Zero point stability ÷ measured value) · 100% o.r. – Repeatability: ± ½ · (Zero point stability ÷ measured value) · 100% o.r. o.r. = of reading Base accuracy for Mass flow liquids 0.15 Volume flow liquids 0.15 Mass flow gases 0.50 Endress+Hauser...
- Page 78 0.65 0.0239 1" 1.80 0.0662 1 ½" 4,50 0.1654 2" 7.00 0.2573 3" 18.00 0.6615 Example for max. measured error ±1.0 ±0.5 ±0.2 18 t/h A0013423 Fig. 38: Max. measured error in % o.r. (example: Promass E, DN 25) Endress+Hauser...
- Page 79 The table below shows the effect on accuracy of mass flow due to a difference between calibration pressure and process pressure. [mm] [inch] [% o.r./bar] 3/8" no influence ½" no influence 1" no influence 1 ½" no influence 2" –0.009 3" –0.020 o.r. = of reading Endress+Hauser...
- Page 80 Zero point stability Promass F (Standard) [mm] [inch] [kg/h] or [l/h] [lb/min] 3/8" 0.030 0.001 ½" 0.200 0.007 1" 0.540 0.019 1 ½" 2.25 0.083 2" 3.50 0.129 3" 9.00 0.330 4" 14,00 0.514 6" 32.00 1.17 10" 88.00 3.23 Endress+Hauser...
- Page 81 = of reading; 1 g/cc = 1 kg/l; T = medium temperature • Mass flow and volume flow (liquid): ±0.05% o.r. • Mass flow (gas): ±0.25% o.r. • Density (liquid): ±0.00025 g/cc • Temperature: ±0.25 °C ± 0.0025 · T °C; (±0.5 °F ± 0.0015 · (T–32) °F) Endress+Hauser...
- Page 82 – Max. measured error: ± (Zero point stability ÷ measured value) · 100% o.r. – Repeatability: ± ½ · (Zero point stability ÷ measured value) · 100% o.r. o.r. = of reading Base accuracy for Mass flow liquids 0.15 Mass flow liquids, optional 0.10 Volume flow liquids 0.15 Mass flow gases 0.35 Endress+Hauser...
- Page 83 • Temperature: ±0.5 °C ± 0.005 · T °C; (±1 °F ± 0.003 · (T - 32) °F) Zero point stability Zero point stability [mm] [inch] [kg/h] or [l/h] [lb/min] 3/8" 0.20 0.007 ½" 0.65 0.024 1" 1.80 0.066 1 ½" 4,50 0.165 2" 7.00 0.257 Endress+Hauser...
- Page 84 Influence of medium temperature When there is a difference between the temperature for zero point adjustment and the process temperature, the typical measured error of the sensor is ±0.0002% of the full scale value / °C (±0.0001% of the full scale value/°F). Endress+Hauser...
- Page 85 – Calibration range: 0.0 to 1.8 g/cc, +10 to +80 °C (+50 to +176 °F) – Operation range: 0.0 to 5.0 g/cc, –50 to +150 °C (–58 to +302 °F) • Temperature: ±0.5 °C ± 0.005 · T °C; (±1 °F ± 0.003 · (T - 32) °F) Endress+Hauser...
- Page 86 [lb/min] [% o.r.] 250 : 1 2.646 1.875 100 : 1 6.615 0.750 25 : 1 26.46 0.188 10 : 1 1800 66.15 0.100 2 : 1 9000 330.75 0.100 o.r. = of reading; Design fundamentals ä 87 Endress+Hauser...
- Page 87 – Max. measured error: ± (Zero point stability ÷ measured value) · 100% o.r. – Repeatability: ± ½ · (Zero point stability ÷ measured value) · 100% o.r. o.r. = of reading Base accuracy for Mass flow liquids 0.15 Volume flow liquids 0.15 Mass flow gases 0.50 Endress+Hauser...
- Page 88 0.20 0.007 ½" 0.65 0.024 1" 1.80 0.066 1 ½" 4,50 0.165 2" 7.00 0.257 Example for max. measured error ±1.0 ±0.5 ±0.2 18 t/h A0013428 Fig. 42: Max. measured error in % o.r. (example: Promass P, DN 25) Endress+Hauser...
- Page 89 The table below shows the effect on accuracy of mass flow due to a difference between calibration pressure and process pressure. [mm] [inch] [% o.r./bar] 3/8" –0.002 ½" –0.006 1" –0.005 1 ½" –0.005 2" –0.005 o.r. = of reading Endress+Hauser...
- Page 90 • Temperature: ±0.5 °C ± 0.005 · T °C; (±1 °F ± 0.003 · (T - 32) °F) Zero point stability Zero point stability [mm] [inch] [kg/h] or [l/h] [lb/min] 3/8" 0.20 0.007 ½" 0.65 0.024 1" 1.80 0.066 1 ½" 4,50 0.165 2" 7.00 0.257 Endress+Hauser...
- Page 91 Influence of medium temperature When there is a difference between the temperature for zero point adjustment and the process temperature, the typical measured error of the sensor is ±0.0002% of the full scale value / °C (±0.0001% of the full scale value/°F). Endress+Hauser...
- Page 92 – Max. measured error: ± (Zero point stability ÷ measured value) · 100% o.r. – Repeatability: ± ½ · (Zero point stability ÷ measured value) · 100% o.r. o.r. = of reading Base accuracy for Mass flow liquids 0.15 Volume flow liquids 0.15 Mass flow gases 0.50 Endress+Hauser...
-
Page 93: Operating Conditions: Installation
Standard: IP 67 (NEMA 4X) for transmitter and sensor Shock resistance According to IEC 68-2-31 Vibration resistance Acceleration up to 1 g, 10 to 150 Hz, following IEC 68-2-6 CIP cleaning SIP cleaning Electromagnetic compatibility As per IEC/EN 61326 and NAMUR recommendation NE 21 (EMC) Endress+Hauser... -
Page 94: Operating Conditions: Process
Only for mounting sets with threaded connections: Viton: –15 to +200 °C ( –5 to +392 °F) EPDM: –40 to +160 °C (–40 to +320 °F) Silicon :–60 to +200 °C (–76 to +392 °F) Kalrez: –20 to +275 °C (–4 to +527 °F) Endress+Hauser... - Page 95 • For gas measurement the following rules apply: – Flow velocity in the measuring tubes should not be more than half the sonic velocity – The maximum mass flow depends on the density of the gas: formula ä 73 (0.5 Mach). Endress+Hauser...
- Page 96 = kinematic viscosity [m d = inside diameter of measuring tubes [m] g = mass flow [kg/s] K to K1 = constants (depending on nominal diameter) To compute the pressure loss for gases, always use the formula for Re 2300. Endress+Hauser...
- Page 97 6.10 10 1.33 10 –3 [mbar] 10000 DN 25 DN 8 DN 15 DN 40 DN 50 DN 100 1000 DN 150 DN 80 DN 250 0.01 0.001 1000 [t/h] a0001396 Fig. 44: Pressure loss diagram for water Endress+Hauser...
- Page 98 40.50 10 1.44 10 5.00 10 2.30 10 –3 [mbar] 10000 DN 40 DN 25 DN 15 DN 50 DN 8 DN 80 1000 0.01 0.001 1000 [t/h] a0004606 Fig. 45: Pressure loss diagram for water Endress+Hauser...
- Page 99 5.4 10 6.6 10 –3 3.0 10 2.0 10 4.3 10 –3 [mbar] 10000 DN 2 DN 4 DN 1 1000 1000 [kg/h] a0003595 Fig. 46: Pressure loss diagram for water Standard version High pressure version Endress+Hauser...
- Page 100 1.72 10 1.20 10 –3 Pressure loss data includes interface between measuring tube and piping [mbar] 1000 DN 8 DN 15 DN 25 DN 40 DN 50 0.01 [t/h] a0004607 Fig. 47: Pressure loss diagram for water Endress+Hauser...
- Page 101 DN 40 DN 50 DN 25 DN 15 * DN 25 * DN 40 * DN 8 DN 15 DN 80 DN 50 * 0.01 [t/h] a0004608 Fig. 48: Pressure loss diagram for water Standard versions Full bore versions (*) Endress+Hauser...
- Page 102 Pressure loss diagram for water Pressure loss (US units) Pressure loss ist dependent on fluid properties nominal diameter. Consult Endress+Hauser for Applicator PC software to determine pressure loss in US units. All important instrument data is contained in the Applicator software programm in order to optimize the design of measuring system.
-
Page 103: 10.1.10 Mechanical Construction
Compact version Remote version Promass H / DN Compact version Remote version Promass I / DN 15FB 25FB 40FB 50FB Compact version Remote version "FB" = Full bore versions of Promass I Promass S / DN Compact version Remote version Endress+Hauser... - Page 104 2" Compact version Remote version "FB" = Full bore versions of Promass I Promass S / DN 3/8" 1/2" 1 ½" 2" Compact version Remote version Promass P / DN 3/8" 1/2" 1 ½" 2" Compact version Remote version Endress+Hauser...
- Page 105 • DIN 11864-2 Form A (flat flange with groove) stainless steel 1.4404/316L • VCO connection stainless steel 1.4404/316L stainless steel 1.4404/316L • Threaded hygienic connections DIN 11851/ DIN 11864-1, Form A / ISO 2853 / SMS 1145 • Tri-Clamp (OD-tubes) stainless steel 1.4404/316L Endress+Hauser...
- Page 106 • DN 8 to 100 (3/8" to 4"): stainless steel 1.4539/904L • DN 150 (6"): stainless steel 1.4404/316L • DN 250 (10"): stainless steel 1.4404/316L; manifold: CF3M • DN 8 to 150 (3/8" to 6"): Alloy C-22 2.4602/N 06022 Endress+Hauser...
- Page 107 "Technical Information" document on the device in question. This can be downloaded as a PDF file from www.endress.com. section ä 109 A list of the "Technical Information" documents available is provided in the "Documentation" ä 105 Process connections Endress+Hauser...
-
Page 108: 10.1.11 Human Interface
CE mark The measuring system is in conformity with the statutory requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-tick mark The measuring system is in conformity with the EMC requirements of the "Australian Communications and Media Authority (ACMA)". -
Page 109: 10.1.13 Ordering Information
The Endress +Hauser service organization can provide detailed ordering information and information on the order codes on request. 10.1.14 Accessories transmitter and the sensor ä 54. Various accessories, which can be ordered separately from Endress+Hauser, are available for the 10.1.15 Documentation • Flow measuring technology (FA00005D) • Technical Information –... -
