System status
Install a firmware image from a system reboot using the CLI
FortiGate-50R Installation and Configuration Guide
This procedure installs a specified firmware image and resets the FortiGate unit to
default settings. You can use this procedure to upgrade to a new firmware version,
revert to an older firmware version, or to re-install the current firmware.
Note: There are a few variations on this procedure for different FortiGate BIOS versions. These
variations are explained in the procedure steps that are affected. The version of the BIOS
running on your FortiGate unit is displayed when you restart the FortiGate unit while accessing
the CLI by connecting to the FortiGate console port using a null-modem cable.
To run this procedure you:
•
access the CLI by connecting to the FortiGate console port using a null-modem
cable,
•
install a TFTP server that you can connect to from the FortiGate internal interface.
The TFTP server should be on the same subnet as the internal interface.
Before running this procedure you can:
•
Backup the FortiGate unit configuration, use the procedure
settings" on page
•
Backup the NIDS user defined signatures, see the FortiGate NIDS Guide
•
Backup web content and email filtering lists, see the FortiGate Content Protection
Guide.
If you are reverting to a previous FortiOS version (for example, reverting from FortiOS
v2.50 to FortiOS v2.36) you may not be able to restore your previous configuration
from the backup configuration file.
Note: Installing firmware replaces your current antivirus and attack definitions with the
definitions included with the firmware release that you are installing. When you have installed
new firmware, use the procedure
page 75
to make sure that antivirus and attack definitions are up-to-date.
To install firmware from a system reboot
1
Connect to the CLI using the null modem cable and FortiGate console port.
2
Make sure that the TFTP server is running.
3
Copy the new firmware image file to the root directory of your TFTP server.
4
Make sure that the internal interface is connected to the same network as the TFTP
server.
5
To confirm that the FortiGate unit can connect to the TFTP server, use the following
command to ping the computer running the TFTP server. For example, if the TFTP
server's IP address is 192.168.1.168:
execute ping 192.168.1.168
64.
"Manually updating antivirus and attack definitions" on
Changing the FortiGate firmware
"Backing up system
59
