Services
Grouping services
128
5
Specify a Source and Destination Port number range for the service by entering the
low and high port numbers. If the service uses one port number, enter this number in
both the low and high fields.
6
If the service has more than one port range, select Add to specify additional protocols
and port ranges.
If you mistakenly add too many port range rows, select Delete
extra row.
7
Select OK to add the custom service.
You can now add this custom service to a policy.
To make it easier to add policies, you can create groups of services and then add one
policy to provide or block access for all the services in the group. A service group can
contain predefined services and custom services in any combination. You cannot add
service groups to another service group.
1
Go to Firewall > Service > Group.
2
Select New.
3
Enter a Group Name to identify the group.
This name appears in the service list when you add a policy and cannot be the same
as a predefined service name.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and
the special characters - and _. Other special characters and spaces are not allowed.
4
To add services to the service group, select a service from the Available Services list
and select the right arrow to copy it to the Members list.
5
To remove services from the service group, select a service from the Members list and
select the left arrow to remove it from the group.
6
Select OK to add the service group.
Figure 9: Adding a service group
Firewall configuration
to remove each
Fortinet Inc.
