Firewall configuration
Viewing the dynamic IP/MAC list
Enabling IP/MAC binding
FortiGate-50R Installation and Configuration Guide
3
Enter the IP address and the MAC address.
You can bind multiple IP addresses to the same MAC address. You cannot bind
multiple MAC addresses to the same IP address.
However, you can set the IP address to 0.0.0.0 for multiple MAC addresses. This
means that all packets with these MAC addresses are matched with the IP/MAC
binding list.
Similarly, you can set the MAC address to 00:00:00:00:00:00 for multiple IP
addresses. This means that all packets with these IP addresses are matched with the
IP/MAC binding list.
4
Enter a Name for the new IP/MAC address pair.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and
the special characters - and _. Other special characters and spaces are not allowed.
5
Select Enable to enable IP/MAC binding for the IP/MAC pair.
6
Select OK to save the IP/MAC binding pair.
1
Go to Firewall > IP/MAC Binding > Dynamic IP/MAC.
!
Caution: Make sure that you have added the IP/MAC Address pair of your management
computer before enabling IP/MAC binding.
1
Go to Firewall > IP/MAC Binding > Setting.
2
Select Enable IP/MAC binding going through the firewall to turn on IP/MAC binding for
packets that could be matched by policies.
3
Select Enable IP/MAC binding going to the firewall to turn on IP/MAC binding for
packets connecting to the firewall.
4
Configure how IP/MAC binding handles packets with IP and MAC addresses that are
not defined in the IP/MAC list.
Select Allow traffic to allow all packets with IP and MAC address pairs that are not
added to the IP/MAC binding list.
Select Block traffic to block packets with IP and MAC address pairs that are not added
to the IP/MAC binding list.
5
Select Apply to save your changes.
IP/MAC binding
139
