IPSec VPN
Redundant IPSec VPNs
Configuring redundant IPSec VPN
FortiGate-50R Installation and Configuration Guide
Action
ENCRYPT
VPN Tunnel
The VPN tunnel name added in step 1. (Use the same tunnel for all encrypt
policies.)
Allow inbound
Select allow inbound.
Allow outbound Do not enable.
Inbound NAT
Select inbound NAT if required.
Outbound NAT Select outbound NAT if required.
See
"Adding an encrypt policy" on page
6
Arrange the policies in the following order:
•
outbound encrypt policies
•
inbound encrypt policy
•
default non-encrypt policy (Internal_All -> External_All)
Note: The default non-encrypt policy is required to allow the VPN spoke to access other
networks, such as the Internet.
To ensure the continuous availability of an IPSec VPN tunnel, you can configure
multiple connections between the local the FortiGate unit and the remote VPN peer
(remote gateway). With a redundant configuration, if one connection fails the
FortiGate unit will establish a tunnel using the other connection.
Configuration depends on the number of connections that each VPN peer has to the
Internet. For example, if the local VPN peer has two connections to the Internet, then
it can provide two redundant connections to the remote VPN peer.
A single VPN peer can be configured with up to three redundant connections.
The VPN peers are not required to have a matching number of Internet connections.
For example, between two VPN peers, one can have multiple Internet connections
while the other has only one Internet connection. Of course, with an asymmetrical
configuration, the level redundancy will vary from one end of the VPN to the other.
Note: IPSec Redundancy is only available to VPN peers that have static IP addresses and that
authenticate themselves to each other with pre-shared keys or digital certificates. It is not
available to VPN peers that have dynamically assigned IP addresses (dialup users). Nor is it
available to VPN peers that use manual keys.
Prior to configuring the VPN, make sure that both FortiGate units have multiple
connections to the Internet. For each unit, first add multiple (two or more) external
interfaces. Then assign each interface to an external zone. Finally, add a route to the
Internet through each interface.
169.
Redundant IPSec VPNs
175
