Message Message on
No. Column Readout
I 72 COLUMN FAIL
I 73 ROTAT FAIL
I 74 LOCK FAILURE
I 75 BUTTON FAIL
I 76 FAILURE
I 77 PEDAL FAIL
I 78 BLOWN FUSE
I 79 FAILURE
I 80 STEREOTIX
Message on
Control Console
COLUMN MOTION
FAILURE
ROTATION BRAKE
FAILURE
ARM LOCK FAILURE
BUTTON SECURITY
FAILURE
DETECTOR FAILURE
PEDAL SECURITY
FAILURE
BLOWN FUSE
POWER SUPPLY
FAILURE
STEREOTIX
INTERDICTION
Explanation/meaning
of message
Elevator is not functioning
correctly .
Brake rotation is not
functioning correctly.
Arm lock is not functioning
correctly .
Failure in operator presence
interlock in control buttons.
Fault in detector.
Failure in operator presence
interlock for compression
pedal.
A fuse has failed.
A power supply has failed.
Movements requested
(elevator or rotation) cannot
be made by interlock with
Stereotix 2 option.
3-8
SENOGRAPHE DMR+
om 5128689-2-100
Corrective Action
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
- If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
-Switch OFF, and switch ON.
If fault continues, note ALL
messages and contact
GEMS Field Service.
1.Connect controller of Stereotix 2
to Senographe.
2.Connect positioner to controller.
3.Switch controller on.
4.Move Stereotix 2 paddle up to
end of travel.
5.If fault continues, note ALL
messages and contact
GEMS Field Service.
